Bently Nevada 3300 NSv Armored Proximity Probe – 330904-00-06-05-01-00
Description
Factory-new armored proximity probe with stainless steel protection for harsh industrial environments. Features superior chemical resistance and side-view performance. Includes connector protector for reliable operation in compressors, turbines, and heavy machinery.
Key Advantages
- Stainless steel armor for impact protection
- M8x1 thread with connector protector
- 0.5m short-length cable for tight spaces
- Direct replacement for 3300 RAM probes
Technical Specifications
| Brand | Bently Nevada |
| Full Part Number | 330904-00-06-05-01-00 |
| Suffix Details | -00- : 0mm unthreaded length -06- : 60mm armored case -05- : 0.5 meter cable -01- : ClickLoc with protector -00- : No agency approval |
| Linear Range | 0.25-1.75mm (10-70 mils) |
| Scale Factor | 7.87 V/mm ±20% |
| Probe Resistance | 4.0Ω ±0.5Ω |
| Temp Range | -52°C to +177°C |
| Cable Type | 75Ω coaxial FEP-insulated |
Installation Guide
- Optimal gap: 1.0mm (40 mils)
- Max torque: 0.56 N•m (5 in•lb)
- Thread engagement: ≤12mm
- Min bend radius: 25.4mm (1.0 in)
Compatibility
Direct electrical & mechanical replacement for 3300 RAM probes. Works with all 3300 XL NSv Proximitors. Armored version provides extra durability.
Certifications
Agency approval: 00 (Not Required)
Package Contents
- Armored probe with 0.5m cable
- ClickLoc connector with protector
- 12-month warranty
- Factory documentation
FAQ
Q: What’s the armor material?
A: AISI 304 stainless steel for maximum protection.
Q: Minimum target size?
A: 13mm (0.5 in) diameter recommended.
Q: Pressure rating?
A: Viton O-ring seal – contact for pressure testing.
Q: Shipping time?
A: Global delivery via FedEx/UPS/DHL in 3-5 days.
