Description
Compact Armored Sensor for Smaller Machinery
The Bently Nevada 330904-00-12-05-02-00 is a new-generation 8mm proximity probe. It features a stainless steel armored case and M8 metric thread. This sensor is perfect for monitoring vibration on pumps, motors, and small turbines where space is limited.
Key Product Advantages
- Small & Strong: M8x1 thread and armored body fit tight spaces while resisting damage.
- Improved Chemical Resistance: Better than older 3300 RAM probes for harsh process environments.
- Easy Upgrade: Directly interchangeable with previous 3300 RAM probes and cables.
- Wide Frequency Response: 0 to 10 kHz range for capturing detailed vibration data.
- Global Stock: New & original, shipped in factory packaging with full 12-month warranty.
Part Number Structure Explained
The model code 330904-00-12-05-02-00 defines your exact probe:
- Base: 330904 – 3300 NSv Proximity Probes, M8x1 Thread, With Armor
- • -00: Unthreaded Length = 0 mm (Fully Threaded)
- • -12: Overall Case Length = 120 mm
- • -05: Cable Length = 0.5 Meter (20 in)
- • -02: Connector = ClickLoc Coaxial
- • -00: Agency Approval = Standard
Technical Specifications
- Product: Bently Nevada 3300 NSv Proximity Probe
- Model: 330904-00-12-05-02-00
- Electrical Data:
- Probe Resistance: 4.0 Ω ± 0.5 Ω
- Linear Range: 1.5 mm (60 mils)
- Recommended Gap: 1.0 mm (40 mils)
- Sensitivity (ISF): 7.87 V/mm (200 mV/mil)
- Frequency: 0 to 10 kHz
- Mechanical Data:
- Thread: M8 x 1.0
- Max Thread Engagement: 12 mm
- Case Material: Armored AISI 304 SST
- Tip Material: PPS Plastic
- Torque (Rec./Max.): 5.1 N•m / 7.3 N•m
- Environmental:
- Temperature: -52°C to +177°C
- Pressure Seal: Viton O-ring
- Cable Bend Radius: 25.4 mm min.
Typical Applications
- Vibration monitoring on small to medium-sized rotating equipment.
- Process compressors where chemical resistance is important.
- Direct replacement for legacy 3300 RAM probe systems.
- Any application requiring a robust, compact M8 threaded sensor.
Purchase Information
- Condition: 100% New & Original, Factory Sealed.
- Warranty: Full 12-month manufacturer warranty included.
- Shipping: Express delivery available via FedEx, UPS, and DHL.
- Support: Technical help available: +86 158 8020 0923 (WhatsApp).
Expert FAQ
Compatibility & Performance
- Can I use this to replace my old 3300 RAM probe?
- Yes. The 330904-00-12-05-02-00 is mechanically and electrically interchangeable with 3300 RAM probes. It is a direct upgrade with better chemical resistance.
- Why is the recommended gap 1.0 mm instead of 1.27 mm?
- The 3300 NSv series has a shorter linear range (1.5 mm vs 2.0 mm). Gapping at 1.0 mm (40 mils) centers the measurement in this optimal range for best accuracy.
Installation & Use
- How much should I tighten this M8 probe?
- Use a torque wrench. Tighten to the recommended 5.1 N•m (45 in-lb). Do not exceed 7.3 N•m (65 in-lb). Do not engage more than 12mm of thread.
- What size target does this probe need?
- For accurate radial vibration, the target should be at least 13 mm (0.5 in) in diameter. For smaller shafts, expect some change in sensitivity.
Ordering & Delivery
- Do you have stock for immediate shipment?
- Yes, the 330904-00-12-05-02-00 is typically in stock. We can arrange fast dispatch with FedEx, UPS, or DHL upon order confirmation.
