Description
Product Overview
Original Bently Nevada 3300 NSv Proximity Probe. This sensor is new and sealed in factory packaging. It provides precise vibration and position measurement for machinery protection.
Key Features & Benefits
- Superior Performance: Better side-view and chemical resistance than older probes.
- Easy Upgrade: Direct replacement for previous 3300 RAM system probes.
- Robust Design: Stainless steel case and PPS tip for harsh industrial environments.
- Ready for Installation: Includes full 12-month manufacturer warranty.
Complete Technical Specifications
- Brand: Bently Nevada
- Full Part Number: 330905-02-10-05-02-CN
- 330905 – 3300 NSv Probe, M10x1 thread, no armor
- -02- – Unthreaded Length: 20 mm
- -10 – Overall Case Length: 100 mm
- -05 – Total Cable Length: 0.5 meter
- -02 – Connector: Miniature coaxial ClickLoc
- -CN – Agency Approval: Country Specific
- Measurement Range: 1.5 mm linear (0.25 to 1.75 mm from target)
- Sensitivity (Scale Factor): 7.87 V/mm (200 mV/mil)
- Linearity (DSL): Better than ±0.06 mm
- Frequency Response: 0 to 10 kHz, +0/-3 dB typical
- Temperature Range: -52°C to +177°C (operating & storage)
- Environmental: High chemical resistance, Viton O-ring seal
- Electrical:
- Probe DC Resistance: 4.0 ± 0.5 ohms (for 0.5m length)
- Cable Type: 75 Ω coaxial, FEP insulation
- Mechanical:
- Thread: M10 x 1
- Recommended Torque: Finger tight (Max 0.56 N•m)
- Minimum Bend Radius: 25.4 mm
- Target Size: Minimum 8.9 mm, Recommended 13 mm diameter
Installation & Setup Guide
- Mounting: Hand-tighten only. Do not exceed maximum torque.
- Gap Setting: Set probe tip 1.0 mm from target for best performance.
- Wiring: Use shielded cable. Maximum 305 meters to monitor.
- Target: Ensure flat, clean surface with sufficient diameter.
Compatibility Information
This probe works with Bently Nevada 3300 XL NSv Proximitor sensors. It replaces older 3300 RAM probes without system changes.
Typical Applications & Diagnostic Use
- Critical vibration monitoring on turbines and compressors.
- Shaft position (axial and radial) measurement.
- Key phasor input for speed and phase reference.
- Enables predictive maintenance for unbalance and misalignment.
Certifications & Approvals
Model includes country-specific agency approvals (-CN suffix). Complies with temperature classifications for hazardous areas (EPL Ga, Gc, Dc).
Packaging, Warranty & Shipping
- Package Contents: One probe in original factory packing.
- Warranty: Full 12-month manufacturer warranty.
- Shipping: Fast global delivery via FedEx, UPS, DHL.
Frequently Asked Questions (FAQ)
General & Technical
Is this probe compatible with my existing 3300 system?
Yes. It is a direct mechanical and electrical replacement for 3300 RAM probes.
What makes the NSv probe better?
It offers increased chemical resistance. This is vital for process gas compressors.
Selection & Ordering
How do I choose the right part number?
Match the suffix codes to your needs: thread type, length, cable, and approval.
Can this probe handle high temperatures?
Yes. It operates up to 177°C. Check the temperature schedule for your class.
Installation & Maintenance
What is the correct installation torque?
Finger tight only. Maximum torque is very low at 0.56 N•m (5 in-lb).
My shaft is smaller than 13mm. Can I use this probe?
Yes, but scale factor may change. Reduce the gap setting to minimize error.
How to Choose the Right Probe
- Verify system compatibility (3300 series monitor).
- Check mounting hole thread and required probe length.
- Select cable length to reach the junction box.
- Consider environment (chemicals, temperature).
- For expert help: Contact us via WhatsApp at +86 158 8020 0923.
