The Bently Nevada 330907-05-30-05-02-00 is a 3300 NSv Reverse Mount Probe engineered for harsh industrial environments, particularly process compressors. Featuring M10x1 threads, chemical-resistant construction, and gold-plated ClickLoc connectors, this probe delivers superior reliability in high-vibration applications. Its reverse-mount design and Viton® O-ring seal ensure optimal performance under extreme temperatures (-52°C to +177°C) and pressure differentials.
Technical Specifications
- Model: 330907-05-30-05-02-00
- Suffix Code Breakdown:
- 05-30: M10x1 threaded connection
- 05: 0.5 m (20″) cable length
- 02: Miniature ClickLoc™ connector
- 00: No agency certifications required
- Electrical:
- DC Resistance: 4.0 Ω ±0.5 (0.5m length)
- Field Wiring: 0.2-1.5 mm² (16-24 AWG) shielded triad cable
- Max Cable Run: 305 m (1,000 ft)
- Linear Range: 1.5 mm (60 mils) | Gap Setting: 1.0 mm (40 mils)
- Mechanical:
- Thread Engagement: 15 mm (M10x1)
- Torque: 7.5 N·m (66 in·lb) recommended | 22.6 N·m (200 in·lb) max
- Weight: 14-150 g (0.5-5.3 oz)
- Environmental:
- Operating Temp: -52°C to +177°C (-62°F to +351°F)
- Pressure Seal: Viton® O-ring (avoid sustained < -34°C/-30°F)
Core Advantages
- Chemical Resistance: Superior to 3300 RAM probes in acidic/alkaline environments
- Secure Connections: ClickLoc™ connectors with anti-vibration locking
- TipLoc Technology: Molded PPS tip-to-case bond prevents mechanical failure
