Bently Nevada 330907-05-30-05-12-00 Reverse Mount Probe

Bently Nevada-logo
Categories: , , , , , , , , , SKU: 330907-05-30-05-12-00 Tag:

$175.00 $324.00

0 reviews

Reviews Summary by AI:

17 in stock

Description

Bently Nevada 3300 NSv Reverse Mount Probe

New & Original with 12-month factory warranty. Designed for precision in harsh industrial environments, 330907-05-30-05-12-00 features M10X1 threads, a 0.5-meter FluidLoc™ cable, and enhanced chemical resistance for reliability in process compressors.

Technical Specifications

ParameterDetails
Part Number330907-05-30-05-12-00
Suffix Code Breakdown
  • 05-30: M10X1 reverse-mount threads
  • 05: 0.5 m (20 in) FluidLoc™ cable
  • 12: ClickLoc™ connector with FluidLoc™ cable
  • 00: No certifications required
Electrical
  • DC Resistance (0.5 m): 4.0 Ω ±0.5
  • Linear Range: 0.25–1.75 mm (10–70 mils)
  • Frequency Response: 0–10 kHz (±3dB)
Mechanical
  • Tip Material: Polyphenylene Sulfide (PPS)
  • Case Material: AISI 304 Stainless Steel
  • Max Torque: 22.6 N·m (200 in·lb)
  • Thread Engagement: 15 mm (M10X1)
Environmental
  • Operating Temp: -52°C to +177°C (-62°F to +351°F)
  • Pressure Seal: Viton® O-ring (avoid sustained <-34°C/-30°F)
  • Weight: 14–150 g (0.5–5.3 oz)

Contact Us: For COO or technical support, email sales@ubestplc.com.

Additional information

Weight0.15 kg
Dimensions300 × 330 × 60 mm
