Description
3300 NSv Vibration Sensor: Reliable Machine Health Monitor
Precision proximity probe with 1.8in case length. Made in USA for industrial equipment protection. Measures vibration in pumps, fans, and motors.
Key Features
- Long 1.8in stainless steel case
- 1.0 meter FEP-insulated cable
- ClickLoc connector for secure fit
- Wide temperature range: -52°C to +177°C
- Viton O-ring pressure seal
Core Specifications
- Part Number: 330908-12-18-10-02-00
- Resistance: 4.2 ± 0.5 Ω
- Cable Type: 75Ω coaxial
- Thread Size: 3/8-24 UNF
- Weight: 40g typical
Installation Details
- Max installation torque: 33.9 N•m
- Recommended torque: 11.3 N•m
- Max thread engagement: 0.563 in
- Seal type: Viton O-ring
Technical Performance
- Frequency Response: 0-10 kHz
- Sensitivity: 200 mV/mil ±5%
- Linearity: ±5% within 2mm range
- Shock Survival: 100g peak
Quality & Support
- Made in USA quality
- 12-month product warranty
- No agency approvals needed
Shipping Information
- Fast worldwide shipping
- Carriers: FedEx, UPS, DHL
- Tracking number provided
Common Questions
Q: What’s the delivery time?
A: Usually ships within 24 hours
Q: Can I get longer cables?
A: Yes, 5m and 7m options available
Q: Is calibration needed?
A: Pre-calibrated and ready to install
Q: Waterproof rating?
A: IP67 when connector fully seated
