Bently Nevada 3500/40-03-00 Proximitor Monitor | 3500/40 Series I/O Module

Description

Product Highlights

• Trusted Brand: Made by Bently Nevada in the USA.
• Core Function: Monitors machine vibration and position.
• Easy Setup: Has internal wiring terminals.
• Built-in Safety: Features internal safety barriers.
• Rugged Design: Built for tough factory conditions.

Complete Product Breakdown

• Bently Nevada 3500/40-03-00
  • 3500/40M Proximitor Monitor
    • Product Code: 176449-01
    • Series: 3500 Machinery Protection
  • 3500/40 Proximitor Monitor
    • Type: Proximity Sensor Monitor
  • -03: I/O Module Type
    • Proximitor I/O Module
    • Key Feature: Internal Safety Barriers
    • Key Feature: Internal Terminals
  • -00: Area Approval
    • For Use In: Non-Hazardous Areas
    • Approval: Standard Industrial

Technical Data & Key Selling Points

• Monitoring Performance:
  • Measures shaft vibration and position.
  • Input from eddy current proximity probes.
  • High accuracy for preventive maintenance.
• Electrical Specifications:
  • Power Supply: +24 VDC typical.
  • Signal Output: 4-20 mA and voltage.
  • Frequency Response: 0 to 10 kHz.
• Physical Build:
  • Main Module Size: 9.5″ H x 0.96″ W x 9.52″ D.
  • I/O Module Size: 9.5″ H x 0.96″ W x 6.42″ D.
  • Total Weight: About 3 lbs (1.37 kg).
  • Mounting: Slides into 3500 system rack.
• Environmental Rating:
  • Operating Temperature: 32°F to 158°F (0°C to 70°C).
  • Storage Temperature: -40°F to 185°F (-40°C to 85°C).
  • Robust for plant floor vibration and dust.

What’s in the Box & Support

• One Bently Nevada 3500/40-03-00 Monitor Module.
• One I/O Barrier Module.
• Installation documentation.
• Full 12-month product warranty.
• We ship globally via FedEx, UPS, and DHL.

Frequently Asked Questions (FAQ)

What machines use this monitor?

It is used on turbines, pumps, compressors, and fans. It watches for harmful vibration.

Does it work with all proximity probes?

It works with most standard Bently Nevada eddy current probes. Check the probe model first.

How do I power this module?

It gets power from the 3500 rack. No external power supply is needed.

Can I install it myself?

Installation is simple for trained technicians. Always follow the plant safety rules.

What is a common setup mistake?

A common error is incorrect probe gap setting. This leads to bad data. Always calibrate.

How to Choose This Product

• You need to monitor rotating machine vibration.
• Your application is in a non-hazardous area.
• You use a Bently Nevada 3500 monitoring rack.
• You want reliable, factory-made parts.
• You need accurate data to prevent downtime.
