Bently Nevada 3500/40-03-02 Proximitor Monitor 3500 Series

Description

Product Profile

• Brand: Bently Nevada
• Model: 3500/40-03-02
• Series: 3500 Monitoring System
• Type: Proximitor Monitor Module
• Origin: Made in U.S.A
• Designed for precise shaft position monitoring.

What This Monitor Does

• Measures shaft displacement with high accuracy.
• Converts probe signals into stable output data.
• Supports continuous machine protection.
• Built for demanding industrial plants.

Module Configuration Breakdown

• 3500/40M main monitor module.
• Includes Proximitor I/O with internal barriers.
• Internal terminations reduce wiring errors.
• Designed for hazardous locations.

Safety & Area Approval

• Certified for Class I Zone 2 locations.
• Approved under ATEX standards.
• Compliant with IECEx requirements.
• CSA certified for industrial safety.
• Suitable for explosive gas environments.

Electrical & Measurement Performance

• Optimized for proximity probe signals.
• Stable signal conditioning.
• Low drift over temperature changes.
• Fast response for dynamic shaft motion.
• High repeat accuracy for trend analysis.

Mechanical Specifications

• Main Monitor Size: 241.3 × 24.4 × 241.8 mm
• Main Monitor Weight: Approx. 0.91 kg
• I/O Module Size: 241.3 × 24.4 × 163.1 mm
• I/O Module Weight: Approx. 0.46 kg
• Fits standard 3500 racks.

Environmental Capability

• Designed for harsh industrial conditions.
• Stable operation in vibration-prone areas.
• Resists electrical noise.
• Supports long-term continuous duty.

Installation Experience

• Slides easily into the rack slot.
• Internal barriers simplify compliance.
• Internal terminals speed up wiring.
• Clear labeling aids maintenance teams.

Operational Benefits

• Improves machine availability.
• Reduces unplanned downtime.
• Supports early fault detection.
• Enhances plant safety.

Typical Applications

• Steam and gas turbines.
• Compressors and pumps.
• Oil and gas processing units.
• Power generation facilities.
• Critical rotating equipment.

Package Contents

• One new 3500/40-03-02 Proximitor Monitor.
• Integrated I/O barrier module.
• Protective industrial packaging.

Warranty & Shipping

• Warranty: 12 months.
• Courier: FedEx.
• Courier: UPS.
• Courier: DHL.

Professional FAQ

• Is this monitor suitable for explosive areas?
• Yes. It carries multiple hazardous area approvals.
• Does the I/O module include safety barriers?
• Yes. Barriers are built inside.
• Can this monitor work with existing probes?
• It supports standard Bently Nevada proximity probes.
• How do I choose this model over others?
• Select it when hazardous approval is required.
• Is this monitor good for retrofit projects?
• Yes. It fits standard 3500 racks.
