Description
Product Overview
This is the Bently Nevada 3500/93 Display Interface Module, part number 135799-02. It works with 3500 series monitoring systems. The module shows important machine data on a display. You can view vibration, temperature, and alarms. It helps prevent equipment failure. Setup requires the 3500 configuration software.
Main Features
- Meets API 670: Follows industry safety standards.
- Clear Monitoring: Shows real-time machine protection data.
- Remote Viewing: Allows display far from the rack.
- Power Options: Supports external power for long distances.
- Easy Installation: Simple mounting into 3500 rack.
- Reliable Design: Built for 24/7 industrial use.
Complete Technical Details
- Product Name: Display Interface Module
- Full Model: Bently Nevada 3500/93 135799-02
- Series Compatibility: 3500 Machinery Protection System
- Max Power: 15.5 watts with display
- Data Connection: RS422 communication port
- Protocol Support: Modbus and proprietary formats
- Update Rate: 1 second for fresh data
- Operating Temp: -30°C to +65°C
- Storage Temp: -40°C to +85°C
- Dimensions: 9.50″ x 0.96″ x 9.52″
- Weight: 1.82 pounds
- Humidity: 95% non-condensing
What You Get
- One 3500/93 135799-02 Interface Module
- Product documentation
All items include 12-month warranty. We ship worldwide via FedEx, UPS, DHL.
Installation Notes
Install the module in a 3500 rack slot. Connect to your display unit. Use external power for cables over 100 feet. Configure with 3500 software. The OK LED lights when working.
FAQ – Common Questions
What does this module actually do?
It takes data from the 3500 rack and sends it to a display screen for operators to read.
Can I use it without a display unit?
No. You must connect it to a compatible Bently Nevada display unit to see data.
What is the TX/RX LED for?
It blinks when the module is talking to other rack modules. No blinking means no communication.
Any tips for first-time setup?
Always download the latest rack configuration software first. Older software might not recognize the module properly.
How do I know if I need external power?
If your display is more than 100 feet away, or if you use a backlit display, you need external power.
Is this compatible with old 3500 racks?
Yes, it works with all 3500 series racks. Just make sure you have an open slot.
What’s the delivery time?
We ship in-stock items within 24 hours. Express shipping options are available.
Ordering Information
Verify your rack has an open slot. Order the correct display unit separately. Contact us for bulk pricing or technical questions.
