Description
Bently Nevada 330101-00-32-05-01-CN | 3300 XL 8mm Industrial Probe
???? 330101-00-32-05-01-CN Rugged 8mm Design
- Case: 3.2″ AISI 303/304 stainless steel (32 code)
- Tip: Thick PPS encapsulation with patented TipLoc molding
- Cable: 0.5m (1.6′) with 75 lbf pull strength CableLoc
Suffix Decoder
- 00 = Fully threaded (0″ unthreaded)
- 32= Overall Case Length Option :3.2 in
- 05 = 0.5m total length
- 01 = ClickLoc connector + protector
- CN = Country-specific approvals
Performance Highlights:
- 7.45Ω ±0.5Ω DC resistance @ 0.5m
- 200 mV/mil scale factor (±5% accuracy)
- 2mm linear range (80 mils) from 0.25mm target distance
⚡ Extreme Environment Ready
- Temp Range: -52°C to +218°C (Tip) / +260°C (Cable)
- Humidity: <3% ASF change @ 93% RH for 56 days
- Pressure Seal: Viton® O-ring (untested)
COO certificates available
