Description
PRODUCT: 330901-00-20-10-02-05 | ???????? U.S. Manufactured
★ ATEX/IECEx/CSA Multi-Certified | Compliance: IEC 60079-11 Ed.6
???? Mechanical Configuration
- ▸ 1/4-28 UNF Thread: Max 0.375″ engagement depth
- ▸ Compact Housing: 20 = 2.0 inch (50.8mm) case length
- ▸ Extended Reach: 10 = 1.0m/39″ FEP-jacketed cable
- ▸ ClickLoc Connector: 45 in·lb torque optimized
⚡ Electrical & Thermal Specs
4.2Ω ±0.5 DC resistance @1.0m | 75Ω impedance
Operational resilience: -62°F (-52°C) to +351°F (+177°C)
Critical Note: Avoid sustained exposure below -30°F (-34°C)
???? Advanced Materials
Housing: Corrosion-resistant AISI304 SST
Tip: PPS polymer (500V dielectric strength)
Seal: Viton® O-ring (20-75 Shore A hardness)
Configuration Code 00-20-10-02-05:
00=Zero unthreaded length | 20=2″ case | 10=1.0m cable
02=ClickLoc connector | 05=Multi-agency approval
