Bently Nevada | 990-08-70-03-01 990 Vibration Transmitter 12-35V DC

Description

Bently Nevada 990 Vibration Transmitter: Advanced Protection for Critical Machinery

Core Features

Model 990-08-70-03-01 offers CSA Division 2 certification for hazardous environments. Combines precision vibration monitoring (0-200 µm range) with rugged DIN-mount design. Made in USA.

Key Specifications

• ✔️ Brand/Model: Bently Nevada 990-08-70-03-01
• ✔️ Options: 08 (0-8 mils) | 70 (7m cable) | 03 (DIN mount) | 01 (CSA Div 2)
• ✔️ Accuracy: ±1.5% FS | Response: 5Hz-6kHz
• ✔️ Output: 4-20 mA (2-wire) | Power: 12-35VDC

Setup Essentials

• ???? Mounts with DIN clips/screws
• ???? Maintain 20-55 mil gap between probe & target
• ???? Max loop resistance: 1,000Ω @35VDC

Certifications & Compatibility

• ✅ CSA Division 2 Approved
• ✅ Works with 3300 NSv Probes
• ✅ Supports 3m (10ft) cables max

Package & Support

• ???? Includes transmitter, mounting kit, optional COO
• ???? 12-month warranty
• ???? Ships via FedEx/UPS/DHL (1-3 days)

Industrial Use Cases

• ???? Power plant turbine monitoring
• ???? Pipeline compressor protection

Common Questions

• ❓ Q: Hazardous area compliance?
  A: Yes – CSA Div 2 certified
• ❓ Q: Fault response time?
  A: <3.6mA in 100µs during errors
