Bently Nevada – ETR Probe Without Armor 330191-00-40-50-05

Description

Bently Nevada 3300 XL 8mm Proximity Probe

Part No. 330191-00-40-50-05

Condition: New Original | 12-Month Warranty | Hazardous Area Certified

Product Breakdown for 330191-00-40-50-05

Full Suffix Decoding:

• 330191: Base model (3300 XL 8mm ETR Probe)
• 00: Unthreaded length = 0.0 inch
• 40: Case length = 4.0 inches
• 50: Total cable length = 5.0 meters (16.4 ft)
• 05: Certifications = CSA + ATEX + IECEx

Enhanced Technical Profile

Mechanical Specifications

• Thread Interface: 3/8-24 UNF (Max engagement depth 14.3mm)
• Cable Security:
  • Axial Load Capacity: 330N at probe-cable junction
  • Connector Strength: 270N tensile rating
• Weight Distribution: 323g/m (FEP cable variant)

Deployment Scenarios

• Hydroelectric Plants: Runner shaft eccentricity monitoring
• Marine Propulsion: Thrust bearing wear detection in saltwater environments
• Pharmaceutical Mixers: Seal integrity monitoring in explosive atmospheres

Certification Matrix

• ATEX Directive 2014/34/EU (II 1G Ex ia IIC T4 Ga)
• IECEx IEC 60079-11:2020 (Ex ia IIC T4 Ga)
• CSA C22.2 No. 0-10 (Class I, Division 1)

Configuration Add-Ons

• Armored Variant:
  • 302/304 SST braiding with FEP overjacket
  • Adds 15% weight; maintains flexibility
• Extended Temp Cable:
  • PFA insulation for continuous +260°C service
  • Requires suffix modification (consult factory)

Technical Support: Contact sales@ubestplc.com for installation schematics
