Manufacturer: Bently Nevada | Model: 330104-00-09-10-11-00
Built for fluid-exposed industrial environments with FluidLoc® cable protection. Perfect for long-range monitoring in washdown areas or high-humidity zones.
Technical Specs
- Cable Length: 1.0m (3.3 ft) heavy-duty
- Sealing: IP68-rated Viton® O-ring
- Case Design: 9mm slim profile
- Voltage Range: -17.5 to -26 Vdc (±0.8% drift)
- Bending Radius: 25mm minimum
Suffix Codes Explained for 330104-00-09-10-11-00
- 00: Zero unthreaded length
- 09: Extended 9mm casing
- 10: 1.0m cable length
- 11: FluidLoc® waterproof connector
- 00: Standard industrial use
Industrial Applications
- Wastewater treatment plant agitators
- Marine engine bearing health tracking
- Beverage industry filling machine alignment
Installation Notes
- 1.27mm target gap required
- Max 2000m altitude operation
- 12mA max current consumption
Contact: sales@ubestplc.com for fluid-resistant solutions.
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
