Bently Nevada Proximity Probe 330904-08-15-70-11-05 Buy Now

Description

Bently Nevada 330904-08-15-70-11-05 Proximity Probe

The 3300 NSv Proximity Probe delivers reliable vibration monitoring for industrial equipment. This 330904-08-15-70-11-05 model features a 7m armored cable and superior chemical resistance.

Model Number Explained

• 330904: Base model number
• 08: 80mm unthreaded section
• 15: 150mm total case length
• 70: 7 meter integrated cable
• 11: ClickLoc connector with protector
• 05: Multiple agency approvals

Technical Specifications

• Measurement range: 1.5mm (0.25-1.75mm)
• Accuracy: ±0.06mm across full range
• Cable resistance: 5.9Ω ±0.9
• Frequency response: 0-10kHz (±3dB)
• Minimum target size: 8.9mm diameter
• Max torque: 0.56 N•m (5 in-lb)
• Cable bend radius: Minimum 25.4mm

Professional FAQ

• Q: What makes this probe better than standard models?
  A: Improved chemical resistance and side-view measurement accuracy
• Q: Can I use this in high-pressure applications?
  A: The Viton O-ring provides sealing, but contact us for pressure testing
• Q: How does the 7m cable affect performance?
  A: The 75Ω coaxial design maintains signal integrity over long distances
• Q: What maintenance does this probe require?
  A: Virtually maintenance-free when properly installed

Download Resources

• • Complete 3300 NSv Probe Datasheet
  • Installation Guide for 330904 Series
