Bently Nevada – Proximity Probe 330905-05-25-05-12-00 Without Armor

Description

Product Highlights

The Bently Nevada 330905-05-25-05-12-00 Probe is a factory-fresh sensor with 12-month warranty. Perfect for industrial use, it outperforms older probes like the 3300 RAM model. Features M10x1 threading and a rugged FluidLoc cable for tough conditions.

Why Choose This Probe?

• Longer Case: 250 mm total length (code -25) for deeper installations.
• FluidLoc Cable: Resists chemicals, 0.5m length with ClickLoc connector (code -12).
• Reliable Accuracy: ±0.06 mm error, 7.87 V/mm sensitivity.

Key Specifications for 330905-05-25-05-12-00

• Temperature Range: -52°C to +177°C.
• Gap Setting: 1.0 mm (40 mils) for best results.
• Cable Shield: 0.066 Ω/m resistance.
• Thread Torque: Max 7.5 N•m (finger-tight recommended).

Suffix Decoded

• -05: 50 mm unthreaded section.
• -25: 250 mm case length.
• -12: ClickLoc + FluidLoc cable.

Need Support?

???? sales@ubestplc.com

Document Download here: 3300 XL NSv Proximity Transducer System Datasheet
