Bently Nevada – Proximity Probe Without Armor 330103-00-05-10-02-05

Description

Bently Nevada 3300 XL 8 mm Proximity Probe

Description: The 3300 XL 8 mm Proximity Probe by Bently Nevada is designed for precise vibration and position monitoring in industrial machinery. Featuring an M10x1 thread, PPS probe tip, and stainless steel case, it ensures durability in harsh environments. Ideal for turbomachinery, pumps, and compressors, 330103-00-05-10-02-05 supports intrinsically safe installations and offers reliable performance with CSA, ATEX, and IECEx certifications.

Technical Data

• Brand: Bently Nevada
• Suffix Breakdown:
  • 00: Unthreaded Length (0 mm)
  • 05: Case Length (50 mm)
  • 10: Cable Length (1.0 m)
  • 02: Miniature Coaxial ClickLoc Connector
  • 05: CSA, ATEX, IECEx Approvals
• Linear Range: 0.25–2.3 mm (10–90 mils)
• Accuracy: ±0.50 Ω DC Resistance
• Output Signal: -1 to -17 Vdc
• Operating Temperature: -52°C to +177°C (Standard)
• Cable Resistance: 7.59 Ω ±0.50 (1.0 m)
• Weight: 323 g/m (11.4 oz)

Installation Guidelines

• Thread Engagement: Max 15 mm for M10x1 thread
• Pressure Seal: Viton® O-ring (not pressure-tested by default)
• Field Wiring: 0.2–1.5 mm² (16–24 AWG), shielded triad cable recommended
• Max Cable Length: 305 m (1,000 ft)

Compatibility

• Works with 3300 XL Proximitor Sensors
• Supports ClickLoc miniature coaxial connectors

Certifications

• ATEX, IECEx, CSA: Approved for hazardous zones (Class I/II/III)
• Intrinsic Safety: Compliant with AEx/Ex ia IIC and nA/ec standards

Application Examples

Gas turbine vibration monitoring, centrifugal compressor shaft positioning, hydroelectric generator health analysis.

Contact: For inquiries, email sales@ubestplc.com.

Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
