Bently Nevada Proximity Probes – 330140-08-15-01-05

Description

Description

A heavy-duty 8mm vibration probe 330140-08-15-01-05 designed for industrial monitoring systems. Features CSA/ATEX/IECEx certifications and patented TipLoc/CableLoc technology for enhanced durability. Made in USA with optional Certificate of Origin (COO).

Technical Specifications

Manufacturer: Bently Nevada

Part Number: 330140-08-15-01-05

Key Parameters:

• Case Length: 0.8″ (20.3mm)
• Total Length: 1.5m (4.9′)
• Connector: Miniature ClickLoc coaxial with protector
• DC Resistance: 7.73Ω ±0.50Ω
• Scale Factor (ISF): 7.87 V/mm ±5% (1.5m system)
• Deviation (DSL): <±0.025mm (1.5m system)

Construction & Materials

• Tip Material: Polyphenylene sulfide (PPS)
• Case Material: AISI 303/304 stainless steel
• Seal: Viton® O-ring (330N cable pull strength)
• Weight: 323 g/m (11.4 oz/ft)

Performance Ratings

• • Temperature Range:
  – Standard: -52°C to +177°C
  – Extended: -52°C to +260°C (cable/connector)
• • Humidity Resistance: <3% ASF change at 93% RH for 56 days
• • Pressure Rating: Differential pressure seal (not factory-tested)

Critical Notes

• • Warning: Avoid sustained temperatures <-34°C (-30°F)
• • Linear Range: 2.03mm (80 mil) from 0°C to +45°C
