Bently Nevada Proximity Transducer Assembly 330880-16-00-075-00-02

Description

Description

The Bently Nevada 330880-16-00-075-00-02 is a rugged industrial-grade sensor manufactured in the U.S.A. Featuring an 8 mm 3300 XL probe with 75 mm (2.95 in) penetration depth, this no-frills configuration includes 3/4-14 NPT mounting and IP66-rated housing. Built with conductive PPS thermoplastic and 304 stainless steel components. COO available upon request.

Technical Data

• Manufacturer: Bently Nevada
• Model: 330880-16-00-075-00-02
• Suffix Configuration:
  • A (Probe): 16 – 3300 XL 8 mm (no approvals)
  • B (Standoff): 00 – No adapter
  • C (Penetration): 075 – 75 mm (2.95 in)
  • D (Fittings): 00 – Two plugs/washers only
  • E (Mounting): 02 – 3/4-14 NPT threads
• Weight: 1.44 kg (3.2 lb)
• Key Features:
  • Gold-plated ClickLoc® connector
  • 1-metre FEP-insulated triaxial cable
  • BASEEFA-certified impact resistance
• Electrical Specs:
  • Voltage: -17.5 Vdc to -26 Vdc
  • Scale Factor: 7.87 V/mm ±5%
  • Frequency Response: 0-10 kHz (±3 dB)
