Description
Ethernet-Enabled M340 Automation Processor
The BMXP342020 combines robust processing power with Ethernet connectivity for modern industrial applications. This advanced processor handles complex automation tasks while providing seamless network integration. It delivers reliable performance in demanding factory environments.
Technical Specifications
- Brand: Schneider Electric
- Model: Modicon M340 BMXP342020
- I/O Capacity: 1024 discrete + 256 analog points
- Processing Speed: 6.4-8.1K instructions/ms
- Ethernet Port: 10/100 Mbit/s RJ45
- Memory Capacity: 4MB internal RAM total
- Operating Temperature: 32°F to 140°F (0°C to 60°C)
- Power Consumption: 95mA at 24V DC
- Module Weight: 0.452 lb (0.205 kg)
Communication & Networking
- Ethernet TCP/IP with Modbus TCP messaging
- Dual serial ports for RS232/RS485
- USB programming port 12 Mbit/s
- SNMP network management support
- Web server functionality included
- 2 additional Ethernet module support
Memory & Processing Features
- Program Memory: 3.5MB application space
- Data Storage: 256KB internal memory
- Backup Solution: 8MB memory card included
- Task Management: 64 event tasks
- Execution Speed: 0.12µs Boolean operations
Environmental Specifications
- Protection Class: IP20 industrial rating
- Temperature Range: 0°C to 60°C operation
- Humidity Tolerance: 10-95% non-condensing
- Hazardous Areas: Class I Division 2 certified
- Industrial Standards: IEC 61131-2 compliant
Packaging Options
- Unit Package: Single module box
- Package Size: 4.53″ × 4.33″ × 2.17″
- Unit Weight: 8.642 oz (245g) packaged
- Medium Carton: 15 units per box
- Bulk Pallet: 240 units available
Installation Guide
- Mount in Modicon M340 compatible racks
- Connect to 24V backplane power supply
- Use shielded Ethernet cables for networking
- Monitor eight status LEDs for operation
- Follow all electrical safety standards
Frequently Asked Questions
- What Ethernet features are included?
The processor supports Modbus TCP and web services. - How much memory comes with the unit?
It includes 4MB internal RAM plus 8MB memory card. - Can I add more Ethernet ports?
Yes, you can add two additional Ethernet modules. - What is the maximum network speed?
The Ethernet port runs at 10/100 Mbit/s speed. - Does it support remote monitoring?
Yes, built-in web server enables remote access.
