Description
Rugged M340 Processor with Dual Network Capability
The BMXP3420302H delivers extreme environment performance with advanced networking. This robust processor combines CANopen and Ethernet connectivity for harsh industrial applications. It operates reliably in temperatures from -25°C to 70°C.
Technical Specifications
- Brand: Schneider Electric
- Model: Modicon M340 BMXP3420302H
- I/O Capacity: 1024 discrete + 256 analog points
- Processing Speed: 6.4-8.1K instructions/ms
- Temperature Range: -13°F to 158°F (-25°C to 70°C)
- Memory Capacity: 4MB internal RAM total
- Power Consumption: 135mA at 24V DC
- Network Ports: Ethernet, CANopen, USB
- Module Weight: 0.474 lb (0.215 kg)
Environmental Protection
- Extended operation range: -25°C to 70°C certified
- Conformal coating for moisture resistance
- ATEX Zone 2/22 hazardous area rating
- Gas and dust resistant construction
- Mold and fungal spore protection
- Salt environment compatibility
Network Communication
- Dual Protocol: CANopen and Ethernet TCP/IP
- CANopen Master: 63 devices maximum
- Ethernet Speed: 10/100 Mbit/s auto-negotiation
- USB Interface: 12 Mbit/s programming
- Web Services: Built-in web server capability
- Network Management: SNMP support included
Memory & Performance
- Total RAM: 4MB internal memory
- Program Space: 3.5MB application storage
- Data Memory: 256KB dedicated area
- Backup Solution: 8MB memory card included
- Task Handling: 64 event tasks supported
- Execution Speed: 0.12µs Boolean operations
Packaging & Shipping
- Unit Package: Individual box packaging
- Package Size: 4.72″ × 4.33″ × 2.17″
- Unit Weight: 9.136 oz (259g) complete
- Bulk Package: 15 units per carton
- Shipping Methods: FedEx, UPS, DHL express
Installation Requirements
- Install in Modicon M340 compatible racks
- Use internal backplane power supply
- Connect shielded network cables properly
- Monitor ten status LEDs for operation
- Follow hazardous area installation standards
Frequently Asked Questions
- What environmental certifications does this processor have?
- It carries ATEX Zone 2/22 and IECEx certifications for hazardous locations.
- How many CANopen devices can be connected?
- The processor supports up to 63 CANopen devices as a master.
- What is the operating temperature range?
- It operates from -25°C to 70°C with conformal coating protection.
- Does it include web server functionality?
- Yes, it includes standard web server activation with the memory card.
- What memory capacity is included?
- It features 4MB internal RAM and includes an 8MB memory card.
Support & Documentation
- Download complete technical manual: Product Documentation PDF
- Includes 12-month comprehensive product warranty
- For technical Support, Inquiry, Contact: +86 158 8020 0923
- Expert installation support for harsh environments
