16-Channel Safety Input Module
The BMXSDI1602 is a safety input module for Modicon X80 systems. It has 16 inputs for 24V DC sensors. This module works in tough industrial conditions.
Product Details
- Brand: Schneider Electric
- Model: Modicon X80 BMXSDI1602
- Input Type: 16 channels, 24V DC
- Voltage Range: 19-30V DC
- Input Current: 3.2 mA per point
- Response Time: 6 ms fast
- Power Use: 3.57 W total
- Weight: 0.254 lb (0.115 kg)
Input Specifications
- Sensor Compatible: 2-wire and 3-wire types
- On state: 2 mA or more
- Off state: 1.5 mA or less
- Input impedance: 7500 Ohm
- Reverse polarity protection
- Fuse protection: 0.5A fast blow
Environmental Ratings
- Temperature: -25°C to 60°C
- Protection: IP20 rated
- Humidity: 5-95% non-condensing
- Vibration: 3g resistant
- Shock: 15g resistant
- Coating: Conformal protected
Status Indicators
- Module Run: Green RUN LED
- Channel Status: 16 green LEDs
- Module Error: Red ERR LED
- I/O Status: Red I/O LED
- Sensor Check: Voltage monitoring
Packaging Options
- Single Unit: Individual box
- Box Size: 10.24″ x 7.09″ x 2.17″
- Unit Weight: 11.922 oz (338g)
- Medium Box: 8 units
- Large Box: 64 units
- Shipping: FedEx, UPS, DHL
Installation Guide
- Install in Modicon X80 rack
- Connect 24V DC power
- Wire sensors correctly
- Check all status LEDs
- Use proper fusing
Common Questions
- What sensors work with this module?It works with 2-wire and 3-wire proximity sensors.
- How fast does it respond?It has 6 ms response time for quick detection.
- What is the voltage range?It works from 19V to 30V DC.
- Does it have protection?Yes, reverse polarity and fuse protection.
- How many input points?16 input channels for sensors.
Support & Downloads
- Get full manual: Download Guide
- 12-month warranty included
- Questions? Contact: +86 158 8020 0923
- Fast shipping available
