Description

Allen-Bradley 1785-L46C15 ControlNet Processor

The Allen-Bradley 1785-L46C15 delivers powerful control for industrial automation systems. This robust PLC-5/46C processor features ControlNet connectivity and protected memory for reliable operation.

Technical Specifications

• Brand: Allen-Brady/Rockwell Automation
• Model: 1785-L46C15
• Processor Type: PLC-5/46C ControlNet
• Memory Capacity: 48,000 words
• I/O Capacity: 2048 forcible, 48000 non-forcible
• Backplane Current: 3.3A @ 5V DC
• Network Ports: ControlNet, DH+, Remote I/O
• Scan Time: 0.5ms per rack (ControlNet)
• Thermal Dissipation: 59 BTU/hour
• Operating Temperature: 0°C to 60°C
• Certifications: UL, CE, CSA, C-TICK
• Weight: 1.42 kg (3 lbs)
• Shock Resistance: 30G operational
• Vibration: 1G @ 10-500Hz

Communication Capabilities

• ControlNet: 5M bit/s, 99 nodes per link
• DH+: 57.6K to 230.4K bit/s
• Remote I/O scanning
• RS-232/422/423 serial port
• Coprocessor expansion port

Compatible Systems

• 1771, 1794, 1746, 1791 I/O modules
• Universal Remote I/O chassis
• ControlNet compatible devices
• Hot Backup Cartridge (1785-CHBM)
• EEPROM backup modules

Package & Support

• Single unit packaging
• Global shipping: FedEx, UPS, DHL
• Delivery: 3-7 business days
• Warranty: 12 months
• Technical support available

Frequently Asked Questions

• What networks does this processor support? ControlNet, DH+, and Remote I/O networks.
• Can I expand the memory capacity? Yes, with EEPROM backup modules.
• What is the maximum I/O capacity? 2048 forcible and 48000 non-forcible points.
• Does it support redundant operation? Yes, with hot backup cartridge.
• What environmental conditions does it operate in? 0-60°C with 5-95% humidity.
