Description
Model Code Tree View (330101-00-18-10-12-05)
- Manufacturer: Bently Nevada
- Series Name: 3300 XL
- Sensor Type:3300 XL 8mm Probe
- Configuration Layers
- Base Unit: 330101
- Step 1: Mechanical Size
- 00 → Smooth length: 0.0 in
- 18 → Body length: 1.8 in
- Thread → 3/8-24 UNF
- Step 2: Cable Build
- 10 → Total cable: 1.0 meter
- 12 → ClickLoc connector + FluidLoc sealing cable
- Step 3: Certifications
- 05 → CSA + ATEX + IECEx approvals
Core Performance Data
- Nominal resistance: 7.59 Ω ±0.50
- Typical cable capacitance: 69.9 pF/m
- Usable linear travel: 0.25 mm to 2.3 mm
- Output sensitivity: about 7.87 V/mm
- Recommended vibration gap: ~1.27 mm
- Max monitor wiring distance: up to 305 m
Design Advantages
- TipLoc molding gives stronger tip bonding
- CableLoc pull force rated near 330 N
- FluidLoc option helps stop oil path leaks
- 8 mm body gives better shock resistance
- Stable signal in turbine vibration systems
Materials & Build Quality
- Tip material: PPS high strength plastic
- Housing: AISI 303/304 stainless steel
- Sealing ring: Viton O-ring structure
- Weight reference: about 323 g per meter
Environmental Limits
- Standard temperature: -52°C to +177°C
- Extended probe tip: up to +218°C
- Cable survival: up to +260°C range
- Humidity drift: less than 3% change
Warranty & Shipping Service
- Warranty support: 12 months
- Each probe is checked before shipping
- Courier options: FedEx, UPS, DHL
- Export packing for industrial delivery
FAQ – User Tips & Buying Guide
- What makes the FluidLoc cable important?
It helps block oil or liquid from moving inside the cable. - Is a 1 meter probe good for compact machines?
Yes. It fits short mounting runs with less extra cable. - How do I choose the correct approval code?
Use certified models for hazardous or regulated zones. - What is a common setup mistake in the field?
Wrong gap setting can reduce signal accuracy. - When should I select an 8 mm probe over 11 mm?
Choose 8 mm when space is limited but strength is needed.
