Allen-Bradley 1747-OS401 SLC 5/04 Advanced Process Controller
The Allen-Bradley 1747-OS401 delivers exceptional processing power for complex automation applications. This advanced SLC 500 series processor offers extensive mathematical and instruction capabilities. Discover the full potential of this industrial controller by accessing our comprehensive technical documentation.
Download Complete Technical Specifications Here
Technical Specifications
- Brand & Manufacturer: Allen-Bradley / Rockwell Automation
- Model Number: 1747-OS401
- Product Series: SLC 500 / SLC 5/04 Processor
- Instruction Set: Advanced mathematical and data manipulation
- Addressing Capability: Word-level and bit-level indirect addressing
- Math Functions: ATN, COS, SIN, TAN, natural logarithm
- Special Instructions: SCP, ABS, SWP, ASN, ACS support
- Communication Protocol: Data Highway Plus (DH+)
- Backplane Current: 1.2A @ 5V DC maximum
Environmental Specifications
- Operating Temperature: 0 to 60°C (32 to 140°F)
- Storage Temperature: -40 to 85°C (-40 to 185°F)
- Relative Humidity: 5% to 95% non-condensing
- Operating Shock: 30G (11ms duration)
- Vibration Resistance: 2.5G @ 5-2000 Hz
- Isolation Voltage: 1500V AC (backplane to I/O)
Packaging & Delivery
- Genuine Allen-Bradley 1747-OS401 Processor Module
- Protective industrial packaging ensuring transit safety
- Global shipping via FedEx, UPS, and DHL express services
- Real-time tracking available for all shipments
Expert Frequently Asked Questions
- Q: What advanced math functions does the 1747-OS401 support?
A: This processor supports ATN, COS, SIN, TAN, natural log, and other advanced mathematical operations. - Q: Can I use this processor for process control applications?
A: Yes, the 1747-OS401 is specifically designed for advanced process control with specialized instructions. - Q: What communication protocol does this processor use?
A: It utilizes Data Highway Plus (DH+) for high-speed network communication. - Q: Is the 1747-OS401 compatible with all SLC 500 chassis?
A: It is compatible with SLC 500 chassis designed for SLC 5/04 processors. - Q: Does this processor support indirect addressing?
A: Yes, it supports both word-level and bit-level indirect addressing for flexible programming.
