Description
Genuine Bently Nevada Vibration Probe for Machine Health
This is a factory-new, authentic 3300 NSv Proximity Probes. It monitors shaft vibration and position. The probe provides early warning of machine problems. It helps avoid expensive repairs and production stops.
The sensor delivers accurate data for predictive maintenance. It features improved chemical resistance. This makes it perfect for tough industrial conditions. Use it in compressors, turbines, and other critical equipment.
Your Part Number: 330905-05-05-05-02-05
Product Specifications & Configuration
- Manufacturer & Series: Bently Nevada 3300 NSv
- Complete Part Breakdown:
- Basic Model: 330905 (NSv Probe, M10x1, No Armor)
- Unthreaded Length: -05- = 50 mm
- Case Length: -05 = 50 mm
- Cable Length: 05 = 0.5 Meter
- Connector: 02 = Mini Coaxial ClickLoc
- Approvals: -05 = Multiple Agency
Technical Performance Data
- Measuring Range: 1.5 mm (60 mils) linear range
- Best Gap Setting: 1.0 mm (40 mils)
- Sensitivity: 7.87 V/mm (200 mV/mil)
- Linearity: Better than ±0.06 mm (±2.3 mils)
- Frequency Response: 0 to 10 kHz (±3 dB)
- Target Size: Minimum 8.9 mm, Recommended 13 mm+
- Temperature Range: -52°C to +177°C
- Probe Resistance: 4.0 Ω ± 0.5 Ω
Robust Construction Details
- Case Material: AISI 304 Stainless Steel
- Tip Material: Chemical-Resistant PPS Plastic
- Cable Type: 75 Ω Coaxial with FEP Insulation
- Sealing: Viton O-Ring for Pressure
- Bend Radius: Minimum 25.4 mm (1.0 inch)
Installation Instructions
- Mounting Torque: Finger tight only (Max 0.56 N•m)
- Thread Engagement: M10x1, maximum 15 mm
- Connector Torque: 7.5 N•m (66 in-lb) recommended
- Field Wiring: Use shielded cable, max 305 meters
- Initial Setup: Gap at 1.0 mm, verify system voltage
Compatibility Information
- Direct replacement for 3300 RAM probes
- Mechanically and electrically identical
- Works with standard Bently extension cables
- Connects to 3300 XL NSv Proximitor sensors
Certifications & Approvals
- Multiple international agency approvals
- EPL Ga, Gc, and Dc classifications
- Hazardous area compliant
- Industrial safety standards met
Package Contents & Support
- One genuine Bently Nevada probe
- Original factory packaging
- 12-month manufacturer warranty
- Shipping: FedEx, UPS, DHL available
Typical Applications
- Gas and steam turbines
- Process compressors
- Large pumps and motors
- Power generation equipment
- Petrochemical machinery
Diagnostic Capabilities
This probe helps detect:
- Shaft unbalance and misalignment
- Bearing wear and failure
- Rotor rub and contact
- Thrust position changes
- Mechanical looseness
Frequently Asked Questions
Is this probe really genuine Bently Nevada?
Yes, absolutely. We supply only authentic Bently Nevada products. Each probe comes in original factory sealed packaging.
Will this work with my older 3300 system?
Yes. The NSv probe directly replaces the older RAM version. No wiring changes or adapters needed.
What’s the most common installation mistake?
Over-tightening the probe. Use only finger tight force. Maximum torque is very low at 0.56 N•m.
Can I use this on a small motor shaft?
For shafts under 13 mm diameter, you may need special calibration. Reduce the gap slightly for better results.
How do I connect the ClickLoc connector?
Push until it clicks, then tighten the coupling nut. Use a torque wrench for 7.5 N•m connection.
Do you have longer cable versions?
Yes. Standard lengths include 0.5m (this model), 1m, 5m, and 7m. Contact us for other options.
Is pressure testing available?
Standard probes are not pressure tested. For certified pressure seals, contact Bently Nevada custom design.
My wiring run is very long. Any issues?
Keep field wiring under 305 meters. Use quality shielded cable. Signal may roll off at high frequencies over long distances.
Buying Guide & Selection Tips
- Match the part number exactly for replacement
- Verify thread size is M10x1 for your application
- Choose cable length based on machine layout
- Select NSv for better chemical resistance
- Order matching extension cables if needed
Need help selecting the right probe? Contact our technical team: WhatsApp +86 158 8020 0923
