Description
High-Performance Vibration Monitoring
Optimize your machinery protection with the Bently Nevada 330702-00-26-50-01-05. This certified 3300 XL 11 mm Proximity Probe combines a 5-meter cable with a protective connector. It is engineered for critical applications requiring approved components. Manufactured in the USA and covered by a full 12-month warranty.
Understanding Your Part Number
- Main Product Code
- 330702: 3300 XL 11 mm Proximity Probe, armored, 1/2-20 UNF thread.
- Key Selection Suffixes
- 00: Unthreaded length measures 0.0 in.
- 26: Complete case length is 2.6 in.
- 50: Total cable length is 5.0 m (16.4 ft).
- 01: Connector includes a protector with standard cable.
- 05: Carries Multiple Agency Approvals.
Critical Performance Data
- Electrical & Physical Properties
- DC Resistance (5m): 7.2 Ω ± 0.8 Ω.
- Thread Specification: 1/2-20 UNF.
- Max Thread Engagement: 0.750 in (19.05 mm).
- Build: PPS sensing tip within an AISI 304 stainless steel armored body.
- Installation Specifications
- Mounting Torque (1/2-20 UNF):
- Absolute Max: 45.2 N•m.
- For Best Practice: 15.2 N•m.
- Electrical Connection: Hand-tighten connector only (<0.565 N•m).
- Safe Cable Handling: Minimum bend radius of 1.0 in (25.4 mm).
- Mounting Torque (1/2-20 UNF):
- Environmental Specifications
- Operating Temperature: -51°C to +177°C.
- Storage Advisory: Do not store below -34°C to preserve seal integrity.
- Seal Information: Viton O-ring design (special pressure testing available on request).
What You Receive & Support
- One (1) factory-new probe in original packaging.
- Valid 12-month manufacturer warranty for quality assurance.
- Global express shipping options: FedEx, UPS, DHL.
- Get application advice. Connect with our specialists on WhatsApp for quick answers.
Professional FAQs & Buying Advice
Q: What “Multiple Approvals” does the -05 suffix refer to?
A: The 330702-00-26-50-01-05 meets various international standards for use in hazardous or regulated areas. This is crucial for oil & gas, chemical, and power generation sites.
Q: How is the “-01” cable option different from “-11”?
A: The -01 has a standard cable with a connector protector. The -11 has a sealed FluidLoc cable. Choose -01 for general use; choose -11 for wet or contaminated areas.
Q: Why is the thread engagement length important?
A: You must engage at least 0.750 inches of thread into the mounting hole. This ensures mechanical stability and proper grounding for accurate signal transmission.
Q: Can I get a calibration certificate with this probe?
A: This probe is shipped as a standard OEM unit. For a certified calibration report, please contact us before ordering. Additional lead time may apply.
Q: What is your process for international shipping and customs?
A: We ship globally via major carriers (FedEx/UPS/DHL). We provide all necessary commercial invoices and harmonized system codes to ensure smooth customs clearance for you.
