Description
Dual Axial Probe Housing Assembly for Precision Thrust Monitoring
Product Description
This Bently Nevada 21022-28-05-010-00 housing assembly monitors axial thrust position in industrial machinery. It features two externally mounted 8mm proximity probes that observe shaft movement near thrust bearings. The rugged aluminum housing protects probes from dust, liquids, and harsh environments while allowing external adjustments. Compliant with API 670 standards, it enables safe gap setting via a removable cover.
Key Technical Data
- Brand: Bently Nevada
- Full Model: 21022-28–05–010–00
- Probe Type: 3300 XL 8mm (Code 28)
- Cable Length: 0.5 meter/20″ (Code 05)
- Penetration Depth: 1.0 inch (Code 010)
- Fittings: Uninstalled kit (Code 00)
- Housing Material: Copper-free aluminum alloy
- Sleeve Material: 304 stainless steel
- Weight: 3.6 kg (8 lb)
Installation & Compatibility
Mounts using four machine screws through two 3/4″ NPT threaded holes. Probe sleeves install directly on machine casing. Note: Not compatible with 11mm probes when using 0.5m cables.
Certifications & Contents
Meets API 670 Standard. Package includes: Dual probe housing, two proximity probes, fitting kit (uninstalled), and documentation.
Reliability Assurance
Backed by 12-month warranty. Ships worldwide via FedEx, UPS, or DHL.
Frequently Asked Questions
Q: Are fittings pre-installed?
A: No, fittings come as a separate kit for field installation.
Q: Can I use 11mm probes?
A: Yes, but not with 0.5m cable length option.
