Bently Nevada Dual Axial Probe Housing – 21022-27-05-017-03
Industrial-grade dual probe assembly for axial thrust monitoring. API 670 compliant design with external adjustment capability. Made in USA.
???? Product Configuration Breakdown
- 21022 – Dual Axial Housing Base
- 27 – 3300 XL NSv Probe (Multiple approvals)
- 05 – 0.5m (20″) Probe Cable
- 017 – 1.7″ Probe Penetration
- 03 – Fittings Kit (Seal grips + Reducers)
⚙️ Key Specifications
| Probe Type | 3300 XL NSv (11mm) |
| Cable Length | 0.5 metre (20 in) |
| Penetration Depth | 1.7 inches |
| Housing Material | Aluminum alloy |
| Sleeve Material | 304 Stainless Steel |
| Weight | 3.6 kg (8 lb) |
| Mounting | 4 machine screws + ¾” NPT |
???? Model Comparison
| Feature | This Model (21022-27-05-017-03) | 21022-28-05-010-00 | 21022-26-05-017-03 |
|---|---|---|---|
| Probe Type | XL NSv (Multi-approval) | Standard XL | XL NSv |
| Penetration | 1.7″ | 1.0″ | 1.7″ |
| Fittings Kit | Included (03) | Not included (00) | Included (03) |
| Approvals | Multiple | Standard | Standard |
???? Installation Guide
- Mount using four M8 machine screws
- Probe gap adjustment: 0.8-1.2mm
- Install fittings kit after mounting
- Maintain 50mm clearance around housing
⚠️ Important Notes
- Fittings shipped uninstalled (kit form)
- Removable cover for probe adjustment
- Environmental protection: IP66 equivalent
- Cable length fixed at 0.5m – extensions available
???? Package Contents
- Dual probe housing assembly
- Two 3300 XL NSv probes
- Fittings kit (seal grips + reducers)
- Mounting hardware
- 12-month warranty
???? Global Shipping
FedEx International | UPS Worldwide | DHL Express
❓ Technical FAQ
Q: Maximum shaft temperature?
A: 120°C continuous (177°C peak)
Q: Reducer sizes in fittings kit?
A: ¾-14 to ½-14 NPT (two units)
Q: Replacement probe availability?
A: 3300 XL NSv probes sold separately
Q: Vibration tolerance?
A: 10g @ 100Hz continuous operation
