Description
Introducing the FE6370C: Compact Power for Smart Control
The Flexem FE6370C is a next-generation 7-inch HMI. It belongs to the advanced FE 6300 series. This model delivers better CPU power and more storage. It meets the needs of many different automation projects.
Key Advantages of the FE6370C
- Bright 7-Inch Display: 350-nit brightness for clear viewing.
- Faster Dual-Core CPU: 1GHz Cortex-A7 for smooth operation.
- Ample 4GB Storage: Holds many projects and data logs.
- Ultra-Wide Voltage Input: Works from 9V to 28V DC.
- Rugged IP65 Front: Resists dust and water sprays.
- Multiple Ports: USB-C, USB-A, and three serial ports.
- Lightweight Design: Easy to install at under 500 grams.
Complete Technical Specifications
Visual Display Unit
- Screen Size: 7.0 inches diagonal
- Display Technology: TFT LCD with LED backlight
- Aspect Ratio: Standard 16 to 9 widescreen
- Native Resolution: 800 by 480 pixels (WVGA)
- Color Depth: 16.7 million colors (24-bit)
- Typical Brightness: 350 candelas per square meter
- Viewing Angles: 70 degrees horizontal, 50 degrees up, 70 degrees down
- Touch Screen Type: 4-wire resistive (durable)
Internal Hardware
- Main Processor: Dual-core ARM Cortex-A7 running at 1 Gigahertz
- System Memory (RAM): 256 Megabytes of DDR3
- Internal Flash Storage: 4 Gigabytes of eMMC space
- Battery-Backed Clock: Real-Time Clock (RTC) keeps time
- Estimated LCD Lifespan: 50,000 hours of typical use
Communication Interfaces
- Serial Port 1 (COM1): Configurable as RS232, RS485, or RS422
- Serial Port 2 (COM2): RS485 electrical interface
- Serial Port 3 (COM3): Standard RS232 interface
- USB Ports: One USB 2.0 Type-C port, one USB Type-A host port
- Project Download: Via USB slave port or USB flash drive
Electrical & Environmental Ratings
- Nominal Input Voltage: 24 Volts DC
- Operating Voltage Range: 9 to 28 Volts DC
- Typical Power Consumption: Less than 10 Watts
- Power Protection: Built-in surge and lightning protection
- Operating Temperature: 0 degrees Celsius to 50 degrees Celsius
- Storage Temperature: -20 degrees Celsius to 60 degrees Celsius
- Ambient Humidity Range: 10 percent to 90 percent (non-condensing)
- Front Panel Protection: IP65 rating (dust and water jet resistant)
- Rear Panel Protection: IP20 rating (basic protection)
- Vibration Endurance: 2G for 30 minutes in X, Y, Z directions
- Housing Material: High-strength engineering plastic
- Cooling System: Passive natural cooling only
Physical Dimensions & Weight
- Panel Cutout Size: 190mm wide by 136mm high
- Product Overall Dimensions: 204mm wide by 145mm high by 36.6mm deep
- Product Net Weight: Approximately 476 grams
- Mounting Style: Standard panel flush mounting
Reliable Warranty & Fast Shipping
This product is covered by a full 12-month warranty. We ship worldwide using trusted express services: FedEx, UPS, and DHL. Tracking information is provided immediately after dispatch for your peace of mind.
Ideal Application Areas
- Small Machine Operator Panels and Control Interfaces
- PLC and Controller Visualization for Compact Systems
- Building Automation and Environmental Monitoring
- Packaging Equipment and Light Industrial Machinery
- Laboratory Instrument Displays and Data Entry Terminals
- Agricultural Equipment and Outdoor Control Boxes
Professional FAQ for the FE6370C
Q: How do I transfer my HMI project to this panel?
A: You have two easy options. Use a standard USB flash drive, or connect directly via the USB Type-C slave port from your computer.
Q: Can I connect both a printer and a barcode scanner?
A: Yes. Use the USB Type-A host port for one device. For a second device, you may need a USB hub or use one of the serial ports if compatible.
Q: Is this HMI suitable for a mobile application with unstable power?
A: Absolutely. Its wide operating voltage range (9V-28V) makes it ideal for vehicle or battery-powered systems where voltage can fluctuate.
Q: What is the best way to clean the touch screen?
A>Use a soft, lint-free cloth slightly dampened with water or a mild screen cleaner. Do not use abrasive cloths or harsh chemicals.
Q: How many communication devices can I connect at once?
A>You can use all three serial ports and the USB port simultaneously. This allows connection to a PLC, a temperature controller, a barcode scanner, and a printer all at the same time.
