Description
Product Overview
The Flexem FE7043WE-UL from the 7000 Series offers a new level of fast response, clear display, and smooth touch work. It uses a strong 1 GHz 2-core CPU for quicker screen jumps and simple data tasks. The unit brings built-in IoT and 4G to help users link sites with low cost and high speed. It fits tight panels and light control jobs that need stable uptime and low power use.
- Quick start with short load time.
- Wide view with bright 4.3-inch LCD.
- IoT ready for remote work.
- Low power for long life.
Technical Details
- Brand: Flexem
- Model: FE7043WE-UL
- Series: 7000 HMI
- Type: Industrial IoT HMI
- Display: 4.3-inch TFT LCD, 16:9
- Resolution: 800 × 480
- Colors: 16-bit
- Brightness: 250 cd/m²
- Viewing Angle: 80° in all directions
- Touch Panel: 4-wire resistive
- CPU: 1 GHz dual-core Cortex-A7
- Memory: 128 MB DDR3
- Flash: 128 MB
- Ethernet: 1 port, 10/100 Mbps
- USB: Type-C OTG port
- Program Load: USB slave or flash drive
- Rated Power: Under 5 W
- Voltage: DC 24 V (9–28 V range)
- Power Safety: Surge design
- Drop Tolerance: Under 5 ms
- Work Temp: 0–50 °C
- Store Temp: -20–60 °C
- Humidity: 10–90% non-condensing
- UV: No strong UV use
- Vibration: 10–25 Hz at 2G
- Front Seal: IP65
- Rear Seal: IP20
- Body: Industrial engineering plastic
- Cutout: 132 × 80 mm
- Size: 138 × 86 × 32 mm
- Weight: 300 g
- Refresh Rate: 60 Hz
- EMC Level: IEC industrial class
- Noise Immunity: Strong against common EMI
- Signal Stability: Low jitter for serial data
- Data Backup: Local flash backup for project files
Key Selling Points
- Fast dual-core CPU improves screen work.
- Small body fits narrow panels.
- Stable 4G IoT cuts wiring cost.
- Low heat design supports long run time.
- Simple Type-C port for fast tools and updates.
- Clear view even in tight rooms.
Warranty
- 12-month warranty from ship date.
- Covers normal use faults only.
- No coverage for wiring mistakes or wrong power.
Shipping Options
- FedEx global service
- UPS fast delivery
- DHL express routes
Professional FAQ
How can I reduce heat in long runs?
Leave small space behind the panel to help air move.
Why does the screen look dim in bright rooms?
Check the backlight level inside the settings menu.
How can I speed up data logs?
Remove unused tags and shorten log cycles.
Why does touch feel rough with gloves?
Use thin gloves or adjust touch sense for better work.
How can I stop port noise in busy plants?
Keep power lines away from data lines and use shielded cable.
