Description
Product Overview
The Flexem FE7370WE-4G is a powerful industrial HMI panel. It combines a bright 7-inch display with built-in 4G connectivity. This all-in-one design removes the need for extra hardware. A dual-core processor ensures smooth operation. It is perfect for demanding factory and automation environments.
Key Features & Benefits
- Built-in 4G IoT – No external gateway required for remote monitoring.
- High-Performance Processor – 1 GHz dual-core for fast response.
- Robust Industrial Design – IP65 front panel and wide voltage input.
- Extensive Protocol Support – Connects to over 100 types of PLCs and devices.
- Edge Computing Ready – Run scripts locally for smarter control.
Complete Technical Specifications
- Brand & Model: Flexem FE7370WE-4G
- Display: 7″ TFT LCD, 1024 x 600, 350 cd/m² brightness
- Touch Screen: 4-wire resistive (industrial grade)
- Core Processor: 1 GHz Dual-Core Cortex-A7
- Memory: 4 GB eMMC + 256 MB DDR3
- Measurement Range: DC 9V to 28V operating voltage
- Resolution & Linearity: 24-bit color, clear and accurate display
- Operating Temp Range: 0°C to +50°C
- Environmental Rating: Front IP65 (NEMA 4), Rear IP20
- Vibration Endurance: 10-25 Hz, 2G (all directions)
- Anti-Interference: Lightning surge protection on power line
- Communication Ports:
- Ethernet: 1 x 10/100 Mbps
- USB: 1x Type-C OTG, 1x Type-A Host
- Serial: COM1 (RS232/485/422), COM2 (RS485), COM3 (RS232)
- Wireless & IoT: Built-in 4G LTE Module, Bluetooth available
- System Capacity: 300 data points, 100 alarms, 30 history logs
- Edge Computing: Supports 20 logic points with scripting
- Program Download: Via USB, Ethernet, or USB drive
Easy Installation & Setup
- Panel cutout size: 190 mm x 136 mm.
- Connect to DC 24V power (9-28V range accepted).
- Use the communication ports to link your PLCs and devices.
- Mounting hardware is included in the box.
Simple Management & Maintenance
- Import and export project files for backup.
- Update the system software remotely over the network.
- User-friendly configuration software reduces setup time.
Certifications & Quality
This product is CE and RoHS certified, meeting international standards for safety and environmental compliance.
What’s in the Box
- Flexem FE7370WE-4G HMI Unit
- Power Connection Cable
- User Manual and Quick Start Guide
- Mounting Clips and Hardware
Warranty & Support
We offer a 12-month warranty against manufacturing defects. Our technical support team is ready to assist you.
Global Shipping
We ship worldwide using reliable carriers: FedEx, UPS, and DHL. Tracking information is provided for every order.
Where to Use It
- Factory Automation and Machine Control
- Renewable Energy Monitoring (Solar/Wind)
- Water and Wastewater Treatment Plants
- Building Management Systems (BMS)
- Remote Pump Station and Pipeline Monitoring
Frequently Asked Questions
Q: Does this HMI need an extra box for 4G internet?
A: No. The 4G module is built inside. You just need to insert a SIM card.
Q: Can I use it in an outdoor enclosure?
A: Yes. The front panel is IP65 rated. Ensure the rear cabinet is properly protected.
Q: How do I program this HMI panel?
A: Use Flexem’s dedicated software on your PC. Transfer projects via USB, LAN, or a USB drive.
Q: What if the power supply fluctuates in my plant?
A: It has a wide input range (9-28V DC) and tolerates brief interruptions under 5ms.
Q: From a maintenance view, is remote access secure?
A: Yes. It supports VPN passthrough for establishing secure connections to your network.
Q: Based on field use, how reliable is the resistive touchscreen?
A: Very reliable. It works with gloves and resists contaminants like dust and moisture, common in industrial settings.
