FPAD710 Intelligent HMI by Flexem – Next-Gen HD Video Playback

Description

Introducing The Flexem FPAD710

• Meet the Flexem FPAD710, a new smart IoT HMI.
• It plays HD video with very clear quality.
• Communication is fast for real-time control.
• Perfect for many factory and shop floor uses.
• Strong build lasts in tough conditions.
• Setup is simple and quick for everyone.

Core Features & Tech Specs

• Brand & Model: Flexem FPAD710 Intelligent HMI
• Brilliant Display: 10.1″ LCD, 1280×800 resolution, 400 nits brightness
• Wide Viewing Angle: 85 degrees from all sides
• Powerful Brain: 4-core 2.0 GHz CPU with Mali G52 GPU
• Fast Memory: 16GB storage & 2GB RAM for smooth operation
• Super Connectivity: 2x Gigabit Ethernet & 2x USB 3.0 ports
• Flexible Ports: Multiple RS232/485/422 serial communication options
• Extra Options: Add WiFi or 4G module for wireless needs
• Clear Sound: Built-in speaker for alarms and prompts
• Sturdy Power: DC 24V input (18V-28V range), under 10W usage
• Power Protection: Isolated adapter with surge protection
• Temperature Range: Works from -10°C to 60°C
• Humidity Handling: 10% to 90% RH, non-condensing
• Shock & Vibration: Tested at 2G for 30 minutes in all directions
• Protection Level: Front face is IP65 (dust/water jet resistant)
• Mounting & Size: Flush mount, cutout 260x202mm, unit 274x214x27mm
• Product Weight: Lightweight at about 1.45 kilograms
• Display Life: Long-lasting backlight for 50,000 hours
• Touch Technology: Reliable 4-wire resistive touch screen

Simple Installation Steps

• Cut a 260mm by 202mm hole in your panel.
• Insert the FPAD710 from the front.
• Secure it with the included mounting clips.
• Connect the 24V DC power wires correctly.
• Plug in your network, USB, and serial cables.

Easy Setup & Maintenance

• Turn it on; the Linux system starts fast.
• Use the touch screen to set language and network.
• Load your application via USB or Ethernet.
• No need for fans; it cools by itself.
• Update software easily through a USB drive.

Works With Your Systems

• Connects to PLCs and sensors using serial ports.
• Use the HDMI port to mirror the display.
• Optional WiFi lets you place it without cables.
• Works with common industrial software.

Approvals & Safety

• CE certified for European markets.
• RoHS compliant, safe for the environment.
• Built for industrial EMC noise immunity.

What You Will Receive

• 1 x Flexem FPAD710 HMI Unit
• 1 x Isolated 24V DC Power Adapter
• 1 x Set of Mounting Clips and Screws
• 1 x Quick Installation Guide

Warranty & Global Shipping

• Full 12-month manufacturer warranty included.
• We ship quickly via FedEx, UPS, and DHL.
• Track your order online from dispatch to delivery.

Where To Use It

• Factory machine operator stations.
• Live video monitoring dashboards.
• Building automation control points.
• Interactive kiosks and information boards.
• Warehouse management and logistics screens.

Built-In Diagnostics

• LED lights show power and system status.
• Check network connection speed easily.
• View system log for error messages.
• Test the touch screen with a built-in tool.

Frequently Asked Questions

• Q: How bright is the screen for sunny areas?
• A: At 400 cd/m², it is clear in most well-lit rooms.
• Q: Can I connect a barcode scanner?
• A: Yes, use the USB 3.0 port for fast peripheral devices.
• Q: What if the power flickers briefly?
• A: It tolerates interruptions under 5 milliseconds without resetting.
• Q: Is the software hard to learn?
• A: No, it uses a standard Linux base common for developers.
• Q: My panel gets hot. Is that a problem?
• A: Ensure ambient air is below 60°C. The unit cools naturally without fans.
