Description
Product Introduction
The Flexem FR-D0808P digital mixed module brings flexibility to your control panel. This compact unit combines input and output functions in one device. It suits various industrial automation tasks. The module connects sensors and actuators with ease. You get reliable performance in a small package. Simplify your system wiring and save space. Enjoy seamless integration into your existing setups. Its robust design ensures stable operation. This module is a smart choice for upgrading machinery.
Complete Technical Specifications
- Brand: Flexem
- Model: FR-D0808P Digital Mixed Module
- Input Channels: 8 points, bidirectional (NPN/PNP compatible)
- Input Rated Voltage: 24 VDC
- Input Operating Range: 0 to 28.8 VDC
- Input Current: 7 mA typical
- Output Channels: 8 points, PNP type
- Output Rated Voltage: 24 VDC
- Output Operating Range: 19.2 to 28.8 VDC
- Output Current Rating: 0.5 A per channel
- Group Current: 0.5 A multiplied by points per group
- Measurement Range: As per voltage operating ranges
- Frequency Response: Designed for standard PLC scan rates
- Sensitivity: Optimized for standard industrial sensor signals
- Linearity: Meets standard industrial control requirements
- Resolution: 1 bit per channel (ON/OFF state)
- Operating Temperature Range: Standard industrial rating (refer to datasheet)
- Environmental Durability: Resists dust, vibrations, and typical noise
- Noise Immunity: High resistance to electromagnetic interference
- Dimensions (H x W x D): 111 x 18 x 76 mm
- Weight: 65 grams
Installation Guide
Mount the module on a standard DIN rail. Ensure proper spacing for heat dissipation. Connect the 24VDC power supply carefully. Use appropriate wire gauges for current loads. Follow the terminal labeling for correct wiring. Always disconnect power before servicing. Secure all connections firmly. Verify voltage levels before powering on.
Setup and Maintenance
Configuration is straightforward. No complex software is needed. Status LEDs provide clear diagnostics. The module requires minimal upkeep. Keep the unit clean and free from debris. Check connections periodically for tightness. Replace the unit if physical damage occurs.
Compatibility Notes
The FR-D0808P works with standard PLC systems. It connects to common NPN and PNP sensors. The module fits standard industrial power supplies. Use it with typical relays and small actuators. It is part of the flexible Flexem module family.
Certifications & Warranty
This product complies with relevant industrial standards. It comes with a 12-month warranty from the purchase date. The warranty covers defects in materials and workmanship.
Shipping & Packaging
- We ship worldwide using FedEx, UPS, and DHL.
- Your order includes one Flexem FR-D0808P module.
- Packaging also includes a datasheet quick guide.
Common Applications
- Conveyor belt control systems
- Packaging machine automation
- Small assembly station control
- Material handling equipment
- Industrial lighting control panels
Diagnostic Features
Each channel has a dedicated LED indicator. These LEDs show real-time input and output status. This allows for quick fault finding. You can easily identify wiring issues. The design supports rapid troubleshooting.
Frequently Asked Questions (FAQ)
Can I use this module with both NPN and PNP sensors?
Yes. The input channels are designed for both types. You do not need to change wiring for different sensors.
What is the maximum load for each output?
Each PNP output can handle up to 0.5 amps. Do not exceed this rating for safe operation.
How do I know if the module is working correctly?
Check the power and channel status LEDs. All LEDs should light up under normal operation. No LED indicates a possible problem.
Is special software required for configuration?
No. This is a standard digital I/O module. It works directly with your PLC’s digital I/O commands.
What if I need more than 8 points?
You can install multiple FR-D0808P modules side-by-side. They work independently on the same DIN rail.
From experience, what is a common wiring mistake?
Users sometimes confuse the common terminal for outputs. Always double-check the common connection for your output device type.
How long does shipping usually take?
Delivery typically takes 5 to 10 business days. This depends on your location and the selected courier.
