IC200CPU005 VersaMax CPU: Compact Brain for Industrial Control
Powerful Mini Controller
GE Fanuc’s IC200CPU005 packs big performance in small size. Runs entire machines with 64 modules and 2048 I/O points. Processes commands in 0.8ms/k speed. Perfect for space-limited control cabinets.
Core Specifications
| Brand | GE Fanuc |
| Model | IC200CPU005 |
| Memory | 64 KB user-configurable |
| I/O Capacity | 2048 points (64 modules max) |
| Speed | 0.8 ms/k boolean execution |
| Ports | RS-232 + RS-485 serial |
| Power | 5V DC (35-135 mA) |
| Clock | Real-time with battery backup |
| Size | 4.2″W × 5″L × 2.7″H |
| Temp Range | 0°C to 60°C |
Easy Installation
- Mount on DIN rail.
- Connect serial port to PC.
- Ensure airflow.
- Ground properly.
- Battery included for clock.
Works With
All VersaMax I/O · GE Fanuc systems · Not for RX3i
Package Contents
- IC200CPU005 CPU module
- Removable battery
- 12-month warranty
Common Questions
Q: Memory expandable?
A: Fixed 64KB – plan program size
Q: Battery life?
A: 2-3 years typical for clock
Q: Cooling requirements?
A: Keep 2″ clearance around unit
Q: Max cable length?
A: 15m for RS-485 · 50ft for RS-232
