GE IC200MDL631 Isolated DC Input Module: High-Speed Industrial Control
Dual-Polarity Input Solution
8-channel DC input module with individual point isolation. Supports both positive and negative logic configurations. Flexible wiring for sourcing or sinking field devices. Ideal for safety-critical applications requiring electrical separation.
Technical Specifications
| Manufacturer | GE Industrial |
| Model | IC200MDL631 |
| Input Type | Isolated DC (8 channels) |
| Voltage Range | 0-150VDC |
| On Threshold | 90-150VDC / 1.0mA min |
| Off Threshold | 0-30VDC / 0.1mA max |
| Isolation Rating | 1500VAC (point-to-point) 250VAC continuous |
| Backplane Power | 5VDC @ 40mA max |
Response Time Configuration
Ultra-Fast Mode
0ms filter + 0.5ms base
0.5ms total
0ms filter + 0.5ms base
0.5ms total
Standard Mode
1.0ms filter + 0.5ms base
1.5ms total (default)
1.0ms filter + 0.5ms base
1.5ms total (default)
Noise-Immune Mode
7.0ms filter + 0.5ms base
7.5ms total
7.0ms filter + 0.5ms base
7.5ms total
Wiring & Isolation
- Individual channel isolation (1500VAC)
- Dual polarity support: positive or negative logic
- 74kΩ input impedance @125VDC
- No external power required
Diagnostic Features
- Per-point status LEDs for instant monitoring
- Green OK LED confirms backplane power
- Hot-swappable in VersaMax systems
- No thermal derating required
Packaging & Support
- Single IC200MDL631 module
- 12-month warranty
- Configuration manual included
- Global shipping: DHL, FedEx, UPS
Technical FAQ
Q: Can I mix positive and negative logic on the same module?
A: Yes, each channel can be independently configured
Q: What’s the maximum voltage tolerance?
A: 150VDC continuous, with transient protection
Q: How do I change response time settings?
A: Through PLC software configuration (default 1.5ms)
Q: Is this suitable for wet environments?
A: Designed for industrial panels; not rated for direct exposure
