GE Fanuc Versamax IC200MDL740 16-Channel DC Output Module
Description
Control industrial devices with the Versamax IC200MDL740 16-channel DC output module. Delivers 0.5A per point at 12/24VDC with ultra-fast 0.2ms switching. Features dual power LEDs for instant diagnostics.
Technical Specifications
| Brand/Series | GE Fanuc Versamax |
| Model Numbers | IC200MDL740 / BXIOOD1624 (ID: FFFF8080) |
| Output Channels | 16-point positive logic |
| Voltage Range | 10.2-30VDC |
| Current Rating | 0.5A continuous / 2.0A inrush (100ms) |
| Switching Speed | 0.2ms ON / 1.0ms OFF |
| Isolation | 1500VAC (1 minute) |
| Backplane Power | 5VDC @ 45mA max |
Core Features
- 16 independent outputs at 0.5A each
- Ultra-fast 0.2ms response for precision control
- FLD PWR + OK LEDs for power monitoring
- Wide voltage input (10.2-30VDC)
Installation Guide
Mount on Versamax backplane. Connect external power (10.2-30VDC) to terminal block. Allow 50mm clearance.
Compatibility
Designed for Versamax PLC systems. Not compatible with RX3i or Series 90-30.
Packaging
- 1x Output Module IC200MDL740
- 12-month warranty
- No certificates included
Shipping
Global delivery via FedEx, UPS, DHL. Tracking provided.
FAQ
Q: Maximum load per channel?
A: 0.5A continuous, 2.0A for 100ms pulses
Q: External power required?
A: Yes – 10.2-30VDC for field devices
Q: Internal fuses included?
A: No – add external circuit protection
