GE Fanuc IC754VBI06MTD QuickPanel View HMI Terminal Monochrome Touchscreen

Description

GE Fanuc IC754VBI06MTD QuickPanel View HMI Overview

• The IC754VBI06MTD is an industrial operator terminal from the GE Fanuc QuickPanel View series.
• It provides clear machine visualization and simple touch control for PLC systems.
• The unit suits factories that need stable and long-term HMI operation.

Display and User Interface

• Display size measures 5.75 inches for compact control panels.
• Screen resolution reaches 320 x 240 pixels for sharp data visibility.
• Monochrome FSTN panel supports 256 gray levels.
• Resistive touchscreen enables accurate input with gloves.

Processing and System Performance

• The terminal uses an Intel XScale PXA255 processor.
• CPU speed runs at 300 MHz for stable graphic performance.
• Operating system runs on Windows CE for reliable operation.

Memory Architecture

• Flash memory capacity reaches 32 MB for application storage.
• Dynamic RAM provides 32 MB for runtime performance.
• Battery-backed SRAM adds 512 KB for data retention.
• ROM includes 512 KB for secure system boot.

Communication Interfaces

• Ethernet port supports 10/100 Mbps industrial networking.
• RS232 interface supports point-to-point device connection.
• RS485 interface allows multi-drop serial communication.
• Communication distance reaches up to 100 meters via Ethernet.

Electrical Specifications

• Nominal supply voltage operates at 24 VDC.
• Input voltage range spans from 12 to 30 VDC.
• Power consumption remains at 12 watts during operation.

Mechanical Construction

• Front bezel uses Valox material for impact resistance.
• Membrane layer uses Lexan for long service life.
• Net weight equals approximately 1.02 kilograms.

Reliability and Lifecycle

• Backlight half-life reaches up to 50,000 operating hours.
• The terminal supports continuous industrial operation.
• Product lifecycle status is discontinued but widely supported in legacy systems.

Typical Industrial Applications

• PLC-based machine monitoring systems.
• Production line status visualization.
• Packaging and material handling control panels.

Packaging, Warranty, and Shipping

• Each unit ships in protective industrial packaging.
• Warranty period covers 12 months.
• Express delivery available via FedEx, UPS, and DHL.

FAQ

• Can this HMI connect to older PLC models?
• Yes, serial ports support legacy PLC communication.
• Is the touchscreen accurate for operator input?
• The resistive panel responds well even with gloves.
• Does the device support Ethernet networking?
• The built-in Ethernet port supports standard industrial networks.
• Is this unit suitable for long shifts?
• The backlight supports extended daily operation.
• Can it replace an existing QuickPanel View unit?
• It fits well in many legacy QuickPanel View installations.
