Product Description
- IC754VBL06CTD is a QuickPanel View HMI from GE Fanuc Emerson.
- Designed for real-time operator interaction in industrial automation.
- Runs on Windows Compact Embedded (CE) operating system.
- Features a 6-inch color TFT display with analog resistive touchscreen.
- Supports machine control, monitoring, and data visualization.
- Developed and downloaded using Proficy View – Machine Edition.
Technical Specifications
- Brand: GE Fanuc / Emerson Automation
- Series: QuickPanel View
- Model: IC754VBL06CTD
- Module Type: Human Machine Interface (HMI)
- Processor: Intel XScale PXA255, 300 MHz
- Display Size: 6.1-inch TFT color screen
- Resolution: 320 × 240 pixels
- Color Depth: 65,536 colors
- Touch Technology: Analog resistive, 12-bit resolution
- Backlight: CCFL, 50,000 hours half-life
- Input Voltage: 12–30 VDC
- Flash Memory: 64 MB
- DRAM: 64 MB SDRAM
- SRAM: 512 KB with battery retention
- Boot Loader: 512 KB
- Memory Expansion: Up to 64 MB via 100-pin DIMM
- Compatible Modules: IC754ACC32MEM, IC754ACC64MEM
Communication & Interfaces
- Two Ethernet RJ45 ports, 10/100 Mbps
- One serial combo port supporting RS232 and RS485
- One dedicated RS232 port
- Two USB interfaces for peripherals
- Supports controller communication and application download
Environmental & Performance Characteristics
- Operating Temperature: Suitable for industrial environments
- Environmental Resistance: Designed for vibration and noise immunity
- EMI Resistance: Stable operation in high-interference areas
- Touch Accuracy: High linearity across X and Y axes
- Response Speed: Fast operator input recognition
Installation Guidelines
- Panel-mount installation with Valox 357U bezel.
- Ensure stable 12–30 VDC power supply.
- Allow ventilation for heat dissipation.
- Use recommended communication cables.
Commissioning & Maintenance
- Configuration via Proficy Machine Edition software.
- Built-in diagnostics simplify troubleshooting.
- Non-replaceable backlight reduces maintenance needs.
- Firmware updates supported through Ethernet.
Compatibility & Expansion
- Compatible with GE PLC and third-party controllers.
- Supports Fieldbus and vendor-specific networks via expansion.
- Built-in web server enables browser-based access.
Certifications & Compliance
- Manufactured to industrial automation standards.
- Designed for long-term industrial operation.
Packaging & Warranty
- Includes one IC754VBL06CTD HMI terminal.
- Standard protective industrial packaging.
- Warranty: 12 months.
- Shipping: FedEx, UPS, DHL available.
Typical Applications
- Manufacturing production lines.
- Process control systems.
- Packaging and material handling.
- Energy and utility monitoring.
Diagnostic Capabilities
- Real-time alarm and status display.
- Network communication monitoring.
- System health and memory status review.
FAQ
- Is this model still in production?
- This product is discontinued but widely supported in legacy systems.
- Can memory be expanded?
- Yes, expansion up to 64 MB using supported DIMM modules.
- What software is required for programming?
- Proficy View – Machine Edition is required.
- Is it suitable for harsh environments?
- Yes, it is designed for industrial noise and vibration.
- Does it support remote access?
- The built-in web server allows browser-based monitoring.
