Description
Genuine Bently Nevada 3300 XL Vibration Probe
This is an original Bently Nevada 3300 XL 11 mm Proximity Probe. The part number is 330707-00-25-10-01-05. It is brand new and made in the USA. This probe is vital for protecting turbines and compressors. It gives early warnings for machine faults. The design is robust for tough industrial sites.
Detailed Product Specifications
- Brand: Bently Nevada
- Series & Type: 3300 XL 11 mm Proximity Probes
- Full Part Code: 330707-00-25-10-01-05
- 330707: 3300 XL 11mm Probe, 5/8-18 UNF
- -00: Unthreaded Length (0.0 in)
- -25: Overall Case Length (2.5 in)
- -10: Total Cable Length (1.0 metre)
- -01: Connector Type (ClickLoc with protector)
- -05: Multiple Agency Approvals
- Mechanical Build
- Thread Size: 5/8-18 UNF
- Max Thread Engagement: 0.938 in
- Case Torque: 15.2 N•m recommended (133 in•lb)
- Case Material: AISI 304 Stainless Steel
- Tip Material: Polyphenylene Sulfide (PPS)
- Electrical & Environmental
- Probe Resistance: 5.9 ± 0.5 Ohms (for 1.0m length)
- Cable Type: 75 Ω Triaxial, FEP insulated
- Temperature Range: -51°C to +177°C
- Pressure Seal: Viton O-ring (Note seal risk below -34°C)
- Minimum Bend Radius: 25.4 mm
FAQs: Quick Answers from Experts
About Product Features
- What does the “05” in the part number mean?It means this probe has multiple agency approvals. It meets various international safety standards.
- Why is the cable “triaxial”?A triaxial cable has an extra shield. This provides better protection against electrical noise for a clean signal.
Installation & Use
- How cold is too cold for this probe?Avoid temperatures below -34°C (-30°F). The sealing O-ring can become brittle and may fail.
- Can I cut and re-terminate the cable if it’s too long?No. The probe and cable are a sealed, tuned unit. Cutting the cable will ruin its electrical performance.
Buying & Support
- What support do I get with my order?You get the full 12-month factory warranty. We also offer technical support. Your order ships fast via FedEx, UPS, or DHL.
Ready to order or need a quote? Message our team on WhatsApp at +86 158 8020 0923 for help.
