IC200DBI001 GE Fanuc DeviceNet Network Interface

Description

IC200DBI001: DeviceNet Remote Network Interface Module

GE Fanuc’s IC200DBI001 enables robust industrial networking for Versamax systems. This DeviceNet slave module connects 8 I/O modules per station across 64 nodes, supporting multiple protocols. Features comprehensive LED diagnostics and Class 1 Div 2 certification for hazardous environments.

Technical Specifications

• Brand: GE Fanuc
• Model: IC200DBI001
• Series: Versamax
• Network Type: DeviceNet remote interface
• Max Nodes: 64 (no bridges required)
• I/O Modules/Station: 8
• Data Rates: 125/250/500 Kbaud
• Data Capacity: 128 bytes input/output
• Power Consumption: 160mA @5V + 10mA @3.3V
• Connector: 5-pin open style (V+, CAN_H, Shield, CAN_L, V0)
• Certifications: CE, cULus, Class 1 Div 2
• Temp Range: 0°C to 60°C

Installation Guide

• Mount using rear latch in industrial rack
• Connect DeviceNet via 5-pin open connector
• Add termination resistor at network end
• Verify green PWR and OK LEDs illuminate

Diagnostics & Maintenance

• LED indicators:
  • PWR: Power status
  • OK: Module operational (green)
  • FAULT: Critical error (red)
  • MOD: Module communication status
• Clean connectors biannually with contact cleaner
• Maintain ambient temperature 0-60°C

Packaging List

• IC200DBI001 module (1 unit)

Shipping Methods

Fast global delivery via FedEx, UPS, DHL with tracking.

Frequently Asked Questions

• Max stations?
• Supports 8 I/O modules per node
• Protocol compatibility?
• Master/slave, peer-to-peer, multi-master
• Hazardous area rating?
• Class 1 Division 2 certified
• Termination required?
• Yes, at network endpoints only
