IC693ALG391 Analog Output Module
DESCRIPTION
Formerly GE Fanuc, now Emerson’s IC693ALG391 delivers precision analog outputs for Series 90-30 PLCs. Features 2 configurable channels with 4-20mA/0-5V outputs. High-resolution control for industrial actuators with 1500V isolation. Note: Discontinued product.
TECHNICAL DATA
| Brand | GE Fanuc/Emerson |
| Model | IC693ALG391 |
| Series | Series 90-30 |
| Outputs | 2 channels |
| Signal Types | 0-20mA/4-20mA 0-5VDC/1-5VDC |
| Resolution | 4µA (4-20mA) 1.25mV (0-5V) |
| Update Rate | 5ms |
INSTALLATION GUIDE
- Fits any slot in 5/10-slot baseplates
- Power: 30mA @5V + 215mA @24V
- External supply: 20-30VDC
- Max compliance voltage: 25V
DIAGNOSTICS & MAINTENANCE
- Single “Module OK” LED
- Check accuracy: ±8µA (4-20mA @25°C)
- Verify calibration annually
- Factory calibrated to 4µA/count
PACKAGING LIST
- IC693ALG391 Output Module
- Mounting hardware
- Installation guide
SHIPPING METHODS
Expedited global delivery via FedEx, UPS, DHL
FAQ
Q: What output signals are supported?
A: 4-20mA, 0-20mA, 1-5V, 0-5V per channel.
Q: Power requirements?
A: Needs 5V (30mA) + 24V (215mA) from backplane or external source.
Q: How to confirm module operation?
A: Check the “Module OK” LED status indicator.
