KEB 07F5C1B-3B0A Combivert F5 Compact AC Drive 0.75kW Vector Control

Description

Product Description

• KEB Combivert F5 Compact is a general-purpose AC drive.
• Model 07F5C1B-3B0A delivers stable motor control.
• Rated power is 0.75 kW for light to medium loads.
• Designed for 3-phase 400V industrial systems.
• Supports sensorless vector control for smooth torque.
• Includes a digital keypad for fast local operation.
• Compact IP20 housing fits tight control cabinets.

Technical Specifications

• Brand: KEB
• Series: Combivert F5 Compact
• Model: 07F5C1B-3B0A
• Rated power: 0.75 kW / 1.8 kVA
• Input voltage: 305–440 VAC, 50/60 Hz
• Input current: 3.6 A
• Output voltage: 0–440 VAC
• Output current: 2.6 A
• Output frequency range: 0–800 Hz
• Control method: Sensorless vector
• EMC filter: Integrated
• Protection class: IP20

Signal Performance & Reliability

• Frequency response supports high-speed motors.
• High resolution improves speed stability.
• Excellent linear control across load changes.
• Strong noise immunity in industrial environments.
• Stable operation under voltage fluctuation.

I/O & Communication

• Analog inputs: 2 for speed and torque.
• Digital inputs: 8 for flexible logic.
• Analog outputs: 2 for feedback signals.
• Relay outputs: 2 for system status.
• Communication ports: RS232 / RS485
• Protocol support: Modbus RTU

Installation Guide

• Mount vertically inside a ventilated cabinet.
• Keep clearance for heat dissipation.
• Use shielded motor cables for best EMC.
• Ground the drive according to standards.

Commissioning & Maintenance

• Digital keypad enables quick parameter setup.
• Five-digit LED display shows real-time status.
• Error codes simplify fault diagnosis.
• Low maintenance due to solid-state design.

Compatibility

• Compatible with standard 3-phase AC motors.
• Works with PLC and HMI systems.
• Supports legacy and modern control networks.

Certifications & Compliance

• Designed to meet global industrial standards.
• Integrated EMC filter reduces emissions.

Typical Applications

• Conveyors and material handling systems.
• Pumps and fans.
• Packaging and processing machines.
• General automation equipment.

Diagnostics & Protection

• Overcurrent and overvoltage protection.
• Thermal monitoring for safe operation.
• Fault memory supports troubleshooting.

Package Contents

• KEB 07F5C1B-3B0A AC drive unit.
• Digital keypad operator 00.F5.060-1000.
• Standard factory packaging.

Warranty & Shipping

• 12-month warranty from delivery date.
• Worldwide shipping via FedEx, UPS, DHL.

FAQ

• Is this drive suitable for variable torque loads?
• Yes. It performs well with fans and pumps.
• Can it replace older F5 models?
• Yes. Parameter migration is usually simple.
• Does the keypad need extra power?
• No. The drive powers the keypad directly.
• How stable is it in hot environments?
• It runs reliably up to 45°C ambient temperature.
