Description
Product Overview
The 09F5C1B-3A0A is a KEB F5 Series inverter. It provides reliable 1.5kW motor control for industrial automation.
Key Features
- High Power: 8.9A max output current
- Safety Monitoring: Short-circuit and earth fault protection
- Multi-Encoder Support: Works with all major encoder types
- Easy Connection: Serial interfaces and potential-free control
- Robust Design: IP20 rated for indoor use
Technical Specifications
- Brand: KEB
- Model: 09F5C1B-3A0A
- Power: 1.5 kW
- Input: 3-phase 400V, 5.7A, 50/60Hz
- Output: 0-480V, 0-800Hz, 4.1A
- Max Current: 8.9 A
- Temperature: -10°C to +45°C
- Enclosure: IP20
- Feedback: Resolver, Incremental, Sin/Cos, Absolute encoder
- Standards: EN 61800-2, -5-1, -3
Installation
Mount in ventilated cabinet. Use shielded cables. Follow local electrical codes.
Maintenance
Easy setup via serial interface. Regular check of connections needed.
Compatibility
Works with most 3-phase motors. Fits standard DIN rail systems.
Certifications
Complies with EN 61800 standards for safety and EMC.
Package & Warranty
- KEB Inverter Unit
- User Manual
- 12-month warranty
Shipping: FedEx, UPS, DHL available.
Applications
- Conveyor systems
- Packaging machines
- Material handling
- Pump control
Diagnostics
Built-in fault monitoring. Clear error codes for quick troubleshooting.
FAQ
What power supply needed?
3-phase 400VAC, 50/60Hz.
Works with single-phase motors?
No, for 3-phase motors only.
Meaning of IP20 rating?
For indoor use only. No water protection.
Drive not starting?
Check power connections first. Review error codes.
Parameter setting difficult?
Basic settings are simple. Manual provides clear steps.
Warranty period?
12 months standard. Contact us for extensions.
