Description
Product Overview
- KEB Axis Drive for demanding automation tasks.
- Model 12F5H1D-3A0A from the Combivert F5 series.
- Designed for precise axis and motion control.
- Supports stable operation in harsh environments.
- Discontinued by manufacturer, limited stock available.
Electrical Performance
- Input supply: 3-phase 400 / 480 VAC.
- Input current: 13.3 A at 400V.
- Input current: 10.6 A at 480V.
- Output current: 9.5 A at 400V.
- Output current: 7.6 A at 480V.
- Control power supply: 24 VDC.
Control & Measurement Capability
- Control mode: PID regulation.
- Sensor inputs support thermocouple types.
- RTD sensors supported for temperature feedback.
- Resolution reaches 0.1°C for fine tuning.
- Fast response improves process stability.
Signal & Output Features
- Relay outputs for alarms and logic control.
- Analog output range: 4–20 mA.
- Clear 4-digit LED display for status view.
- Simple menu structure reduces setup time.
Communication & Integration
- Built-in RS485 communication port.
- Protocol support: Modbus RTU.
- Easy link with PLC and SCADA systems.
- Stable data transfer in noisy plants.
Environmental & Reliability Data
- Operating temperature range: -50°C to +150°C.
- Maximum heatsink temperature: 90°C.
- Efficiency level up to 98%.
- Low heat loss extends service life.
Mechanical & Installation
- Mounting type: Panel mount.
- Compact layout saves cabinet space.
- Front access simplifies wiring.
- Suitable for retrofit projects.
Typical Applications
- Industrial automation lines.
- Temperature-based motion systems.
- Process control equipment.
- Special axis control solutions.
Key Selling Points
- High accuracy with low energy loss.
- Wide temperature tolerance.
- Reliable communication interface.
- Proven KEB F5 platform.
Warranty & Shipping
- 12-month warranty included.
- Fast delivery via FedEx, UPS, DHL.
- Secure industrial-grade packaging.
FAQ
- Can this drive handle continuous high load?
- Yes. Proper cooling ensures stable long-term use.
- Is this model suitable for replacement needs?
- Yes. It works well in legacy F5 systems.
- How complex is parameter tuning?
- The PID setup is simple with basic training.
- Does it support remote monitoring?
- Yes. Modbus RTU allows remote data access.
- What improves its lifespan in harsh plants?
- High efficiency and thermal design reduce stress.
