Description
Leuze Connection Cable Overview
K-D M12A-3P-5m-PVC offers stable signal flow and long life. It is made for sensors and control gear that need clean and safe data transfer. Simple design and strong build make it easy to use in many setups.
Main Features
- Safe power up to 250 VAC/DC
- Up to 4A per contact
- PVC black cable, durable and flexible
- Zinc diecast screw lock, 0.6 Nm torque
- Long bend life with ≥10× sheath diameter bend radius
- Works in cold and warm areas: -30°C to +70°C
- M12A 3-pin angled connector for tight spaces
- Five-meter length for easy routing
Technical Data
- Voltage: 3/4-pin ≤250 VAC/DC, 5-pin ≤125 VAC/DC
- Current: ≤4A per contact
- Insulation: IEC 60664-1, Category I
- Cable Material: PVC, black
- Connector Body: TPU
- Conductor Size: 0.34 mm²
- Sheath Ø: 4.7–5.7 mm
- Bend Radius: ≥10× sheath Ø
- Temperature: Fixed –30°C to +70°C / Flex –5°C to +70°C
Suffix Meaning (Indented Tree)
K-D M12A-3P-5m-PVC
├── K-D
│ └── Connection cable with connector
├── M12A
│ ├── M12 connector
│ └── A = Angular socket
├── 3P
│ └── 3 pins
├── 5m
│ └── Cable length 5 meters
└── PVC
└── PVC cable material
Extra Product Advantages
- Stable locking system improves long-term contact safety
- Strong PVC for vibration-heavy areas
- Easy installation with compact angle design
- Reliable even in low-temperature work zones
- Good for sensors, switches, and automation units
Warranty & Shipping
- 12-month warranty
- Fast global delivery via FedEx / UPS / DHL
FAQ
- What tools are best for tightening the connector?
- A small torque tool at 0.6 Nm keeps the lock safe without damaging the parts.
- Can this cable run near motors?
- Yes. PVC shielding and strong contacts help keep noise low in most motor areas.
- How do I store spare cables?
- Keep them flat and dry. Avoid sharp bends to protect the sheath.
- Does the angle plug help in small cabinets?
- Yes. The M12A angle plug fits well when space is tight and wires need clean routing.
- How long does the lock hold under vibration?
- Based on field use, zinc diecast with self-lock design holds firm for long-term cycles.
