Long Shank Vibration Probe | Bently Nevada 330103-10-14-10-02-CN for Deep Mounting

Description

Industrial-Grade Vibration Probe for Deep Mounting

This is the Bently Nevada 330103-10-14-10-02-CN. It is an 8mm vibration sensor. The probe has a long 100mm smooth section. It is made for mounting through thick machine walls. This M10 metric thread probe gives precise measurement in tight spaces.

Main Product Benefits

• Fits Deep Holes: 100mm unthreaded length installs through thick materials.
• Strong Build: Stainless steel case and PPS tip resist wear and impact.
• Easy to Connect: Standard 1.0-meter cable with secure ClickLoc connector.
• Local Certifications: Can be supplied to meet your country’s safety rules.
• Trusted Performance: Part of the reliable 3300 XL 8mm Probes family.

Part Number Details

Your model 330103-10-14-10-02-CN is built like this:

• Base Number 330103: 8mm Probe, M10x1 Thread, No Armor
  • → Code 10: Smooth Section = 100 mm
  • → Code 14: Total Length = 140 mm
  • → Code 10: Cable = 1.0 Meter
  • → Code 02: Connector = ClickLoc
  • → Code CN: Approval = For Your Country

Technical Specifications

• Product Name: Bently Nevada 3300 XL Vibration Probe
• Model: 330103-10-14-10-02-CN
• Measurement:
  • Range: 2.0 mm
  • Set Gap: -9 Vdc
  • Resistance: 7.59 Ω
• Physical:
  • Thread Size: M10 x 1.0
  • Smooth Part: 100 mm
  • Case Material: Stainless Steel
  • Max Thread Use: 15 mm
  • Install Torque: 11.2 N•m
• Environment:
  • Temp Range: -52°C to +177°C
  • Works in humid conditions
  • Sealed with Viton O-ring

How to Install

• Drill a hole deep enough for the 100mm smooth section.
• The last 15mm must have M10x1 threads for securing.
• Tighten with a torque wrench to 11.2 N•m.
• Connect the ClickLoc cable until it clicks.

What You Get & Support

• In the Box: One probe with 1.0m cable attached.
• Warranty: 12-month warranty against defects.
• Shipping: Fast delivery via FedEx, UPS, or DHL.
• Need Help? Call or message: +86 158 8020 0923 (WhatsApp).

Common Questions Answered

About the Design

• Why does this probe have a long smooth section?
• It lets you mount the probe through a thick plate or insulation. The threads only start at the end to grip the final mounting point.
• How much of the probe should be inside the threaded hole?
• Only the threaded part at the end. Do not put more than 15mm of threads into the hole.

Usage & Selection

• Can I use this on a very hot machine?
• Yes. It works up to 177°C. For higher temperatures, check the temperature schedule chart.
• What does “Country Specific” mean for approvals?
• It means we can provide the 330103-10-14-10-02-CN with the certification your local laws require. Tell us which certificate you need.

Buying & Delivery

• How fast can I get this probe?
• We ship quickly with FedEx, UPS, or DHL. Contact us for exact delivery times to your location.
