Description
Product Overview – Panasonic MSD041A1X Servo Motor Drive
MSD041A1X is a compact servo drive developed by Panasonic for precision motion systems.
It delivers stable 400W output for accurate speed and position control.
The drive supports several control modes and flexible communication options.
It works well in modern automation machines that require high response motion control.
Key Technical Specifications
- Brand Panasonic
- Model MSD041A1X
- Product Type AC Servo Motor Drive
- Input voltage: 100V AC
- Power rating: 400W
- Rated torque: 1.27 Nm
- Maximum torque: 3.82 Nm
- Rated speed: 3000 RPM
- Maximum speed: 5000 RPM
- Operating temperature: 0°C to 45°C
- Approximate weight: 1.5 kg
Control and Communication Capabilities
- Position control mode
- Speed control mode
- Torque control mode
- Pulse train control interface
- RS232 communication port
- RS485 communication interface
- Flexible integration with motion controllers
Feedback System
- Supports incremental encoder feedback
- Supports absolute encoder feedback
- High precision motion response
- Stable signal feedback for closed-loop control
Protection and Safety Functions
- Overvoltage protection
- Overcurrent protection
- Thermal protection system
- Automatic fault detection
- Stable drive performance under heavy load
Manager’s Insight
- The MSD041A1X offers reliable motion performance for small machines.
- Its compact design helps save cabinet space.
- Engineers like its flexible control modes.
- The drive delivers smooth acceleration and precise positioning.
- It is often selected for mid-power servo systems.
Compatible Equipment
- Panasonic AC servo motors
- Industrial motion controllers
- PLC controlled automation systems
- CNC positioning equipment
- Automated production machinery
Typical Application Scenarios
- Packaging machines
- Semiconductor equipment
- Pick and place robots
- Conveyor positioning systems
- Precision assembly machines
Diagnostic Capabilities
- Drive fault monitoring
- Overload status detection
- Communication status diagnostics
- Motor feedback error monitoring
- Real-time operating condition tracking
Shipping and Warranty
- 12-month warranty for manufacturing defects
- 24–48 hour dispatch for available stock
- Secure industrial packaging
- International shipping via FedEx, DHL, and UPS
Professional FAQ
- What motors are compatible with this drive?
- It works with Panasonic servo motors designed for 400W systems.
- Which control mode should be used for positioning machines?
- Position control mode provides accurate movement control.
- How do engineers choose between incremental and absolute encoders?
- Incremental encoders suit simple control. Absolute encoders retain position data.
- What should buyers check before selecting a servo drive?
- Confirm motor power rating, encoder type, and input voltage.
- What is a common installation mistake?
- Incorrect wiring between motor feedback and drive communication ports.
Purchase Consultation
- Technical support and quotation available.
- Contact: +86 158 8020 0923
