New Allen-Bradley 1794-OV16 Digital Output Module | 16-Ch Sinking

Description

Allen-Bradley 1794-OV16 Flex I/O Digital Output Module

Reliable control for your DC devices. The 1794-OV16 module offers 16 outputs in a compact design.

• Perfect for controlling solenoids, valves, and relays.
• Easy to install and replace without powering down.
• Works with multiple network protocols.
• Built-in status lights for each channel.

Technical Specifications

• Brand: Allen-Bradley (Rockwell Automation)
• Model: 1794-OV16
• Series: Flex I/O 1794
• Output Type: Digital, Sinking
• Number of Channels: 16
• Voltage Range: 10 to 31.2V DC
• Current per Channel: 500 mA max
• Total Module Current: 8.0 A max
• Response Time: Off-to-On: 0.5 ms, On-to-Off: 1.0 ms
• Terminal Bases: 1794-TB3, 1794-TB3S
• Communication: ControlNet, DeviceNet, EtherNet/IP, Remote I/O
• Operating Temperature: 0 to 55 °C (32 to 131 °F)
• Protection Rating: IP20
• Status Indicators: 16 yellow LEDs (one per channel)

Warranty & Shipping

This product includes a full 12-month warranty.

We ship worldwide using FedEx, UPS, and DHL.

Frequently Asked Questions

• What does sinking output mean?
• It means the module provides a path to ground for connected devices.
• Can I replace the module while power is on?
• Yes, it supports hot swapping without stopping the system.
• What networks does it work with?
• It works with ControlNet, DeviceNet, EtherNet/IP, and Remote I/O.
• How much current can each output handle?
• Each output can handle up to 500 mA of current.
• What is the IP20 protection rating?
• It protects against finger touch but not against water or dust.
