Description
Premium Vibration Sensor for Critical Machines
The Bently Nevada 3300 XL 11 mm Proximity Probe is built for precision. It monitors vibration and position on turbines, compressors, and pumps. This sensor delivers reliable data. It helps prevent machine failures.
Main Features
- Strong Armored Design: Protects against tough conditions.
- Accurate Readings: Trusted data for maintenance decisions.
- Wide Temperature Use: Works from -51°C to +177°C.
- Easy to Install: Standard thread and quick connector.
- Global Certifications: Approved for use worldwide.
Your Probe Configuration: Model 330702-00-30-50-12-05
- Product Core
- 330702 – 3300 XL Armored 11mm Probe
- Detailed Options
- 00 – Unthreaded Part: 0.0 inch
- 30 – Case Length: 3.0 inch
- 50 – Cable Length: 5.0 meters (16.4 feet)
- 12 – Connector: Miniature Coaxial ClickLoc
- 05 – Approvals: Multiple International
Complete Technical Details
- Identification
- Brand: Bently Nevada
- Full Model: 330702-00-30-50-12-05
- Type: Proximity Probe
- Electrical Data
- Probe Resistance (5m): 7.2 ± 0.8 Ω
- Cable Type: 75 Ω Triaxial, FEP FluidLoc
- Physical Build
- Case Material: AISI 304 Stainless Steel
- Tip Material: Polyphenylene Sulfide (PPS)
- Mounting Thread: 1/2-20 UNF
- Installation Specs
- Use Torque: 15.2 N•m (133 in•lb)
- Max Torque: 45.2 N•m (400 in•lb)
- Connector Torque: Hand tight only
- Environment & Safety
- Work Temperature: -51°C to +177°C
- Bend Radius: Keep over 25.4 mm
- Pressure Seal: Viton O-ring
- Safe Areas (EPL Ga/Gc): T1 to T5
- Safe Areas (EPL Dc): T280°C to T90°C
What You Get & Support
- In the Box:
- 1 x 330702-00-30-50-12-05 Probe
- Product information sheet
- Quality Promise: Full 12-month product warranty.
- Fast Delivery: Shipped via FedEx, UPS, or DHL.
- Weight: 0.17 kg per unit.
Expert Questions & Answers
What is the “50” in the model number for?
It means a 5-meter cable. This probe is made for use with a 5-meter Proximitor sensor. Do not mix different cable lengths.
Can I use this in a very cold place?
Yes, it works down to -51°C. But, the seal may wear faster below -34°C. Plan for more checks in cold weather.
What does “T1 to T5” temperature classification mean?
It shows the probe is safe for different hazard zones. T1 is for the highest ambient temperatures. Always match the class to your area’s requirements.
Is the probe safe for explosive areas?
Yes, with correct temperature class. It has approvals for EPL Ga, Gc, and Dc areas. Confirm your zone rating before you buy.
How do I pick the right model?
First, check your cable length need (5m here). Then, confirm your thread type and area safety class. Our team can help: +86 158 8020 0923.
